User Manual for COMNET 4-Channel 10-Bit Video Receiver with SFP Optical Module Click to enlarge the picture
Contents of the user manual for the COMNET 4-Channel 10-Bit Video Receiver with
- Product category: Signal Extenders COMNET
- Brand: COMNET
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for COMNET Signal Extenders
|
User manual for the COMNET 4-Channel 10-Bit Video Receiver with contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any COMNET product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official COMNET user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a COMNET product will considerably shorten its lifespan!
|
Product description The 4-Channel 10-Bit Video Transmitter with SFP Optical Module from ComNet transmits four 10-bit medium-haul quality digital video channels, using optical SFPs for fiber type, connector, and distance. Plug-and-play design ensures ease of installation and no electrical or optical adjustments are ever required. -
- Transmits up to four 10-bit digital video channels
- Uses interchangeable SFPs for fiber type, distance and connector
- Exceeds all requirements for RS-250C medium haul transmission
- Compatible with all NTSC, PAL, or SECAM CCTV camera systems
- Designed for installation in harsh out-of-plant/unconditioned industrial or roadside operating environments (-40 to +167°F ambient)
- Fully compliant with the environmental requirements of NEMA TS-2 for Traffic Signal Control Equipment
- Voltage transient protection on all power and signal input/ output lines provides protection from power surges and other voltage transient events
- Automatic resettable fuses on all power lines
- Bi-color LED status indicators confirm operating status
- Hot-swappable rack modules
- Can be installed as both standalone or rack mount
In the Box COMNET 4-Channel 10-Bit Video Receiver with SFP Optical Module DC Plug-In Power Supply Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the COMNET 4-Channel 10-Bit Video Receiver with SFP Optical Module in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersCOMNET FVT40SFP Specs | Video Input | 1 Vpp (75 Ohms) | | Overload | >1.5 Vpp | | Bandwidth | 5 Hz to 6.5 MHz | | Differential Gain | <2% | | Differential Phase | < 0.7° | | Tilt | <1% | | Signal-to-Noise Ratio | 67 dB @ maximum optical loss budget | | COAX | Distance: 300' (100 m) camera to fiber optic module to maintain 6 MHz bandwidth | | LED Indicators | Fiber Status
Video Sync Presence
Power | | Optical Connector | ST | | Power | Terminal block | | Video | BNC (Gold-plated center-pin) | | Power | 8 to 15 VDC | | Power Consumption | 3 W | | Rack Mount | From rack
Number of Rack Slots: 1 | | Current Protection | Automatic resettable solid-state current limiters | | Circuit Board | Meets IPC standard | | MTBF | >100,000 hours | | Operating Temperature | -40 to 167˚F (-40 to 75˚C) | | Storage Temperature | -40 to 185˚F (-40 to 85˚C) | | Relative Humidity | 0 to 95% (non-condensing) | | Dimensions (L x W x H) | 6.1 x 5.3 x 2.2" (15.5 x 13.5 x 5.6 cm) | | Weight | Not specified by the manufacturer |
