Product description

Compatible With

eConsole Applications (eCommander, eVision, and eMonitor)
• • ValueLine Series CWGE24MS, CWGE26FX2TX24MSPOE, and CWGE28FX4TX24MS Switches
  • Industrial CNGE5MS, CNGE2FE8MSPOE2, CNGE2FE8MSPOE+, CNGE3FE7MS3, CNGE8MS, CNGE12MS, CNGE20MS, CNGE24MS, CNGE28FX4TX24MS, and CNGE28FX4TX24MSPOE Switches
  • Substation CNGE3FE7MS4 Switch

eConsole Applications (eVision and eMonitor only)
• • ValueLine Series CWGE9MS, CWGE2FE8MSPOE, CWGE2FE24MODMS, and CWGE24MODMS Switches
  • Industrial CNGE2+2SMS[POE][HO], CNGE2FE8MSPOE, CNGE2FE16MS, CNGE3FE7MS2, CNGE8FX4TX4MS, CNGE2FE24MS, and CNGE2FE24MSPOE Switches

eConsole eMonitor Application
• • ValueLine Series CWFE8TX8MS and CWFE8MS/DIN Switches

eConsole Key Functions

Centralized Management
• • Configure all ComNet Ethernet switches in the network at once in a few steps using application wizards such as IP setting group wizard, Firmware upgrade group wizard, and redundant ring (C-Ring) setting wizard
  • Compatible managed switches no longer require individual configuration

Visualized Management
• • Topology View (eVision) can display the complex topologies of ComNet’s Ethernet switches in the local network
  • Different switches can be grouped by different IPs and in different topology windows
  • Health status of the connections will be displayed as different colors for quick visual reference
  • ComNet Topology View helps the administrators to do the management visually, intuitively, and more efficiently

Device Monitoring (eMonitor)
• • eConsole has various mechanisms to monitor the ComNet switches, including an event log and SNMP traps
  • Administrators can be informed of any abnormal events, and the event log can be exported as an Excel file
  • Configuration of the switcher can be saved and the configurations of all switches in local network can be scanned regularly to detect any changes
  • Administrators can be made aware of any unexpected changes to the configurations of the switches
  • ComNet Host Monitor (eMonitor) can automatically ping and check the health statuses of connections among all IP-based devices in the local area network
  • Host Monitor also features IP categorized function, and all IP-based devices can be monitored in groups of different IPs

eConsole Applications

eCommander
• • Automatic device discovery
  • Device status monitoring
  • Syslog events
  • Scan device configuration

eVision
• • Topology views show the topology of connections among all of the switches in the local network
  • IP categorized function
  • Configure the switches into different IP domains
  • Visualized warning system of the health statuses of the connections among the switches
  • Traffic flow analysis of each node
  • Event log that can be exported as an Excel file
  • Administrator can plan the future topology manually in the ‘Edit’ operation mode
  • ComNet Map technology can show network device locations using Google Map Data for automatic device discovery, device status monitoring, syslog events, and scan device configuration

eMonitor
• • IP scan to detect all of the IP-based devices in the local network
  • To check the health statuses of connections of all IP-based devices
  • All of IP-based devices can be grouped and managed by different IP ranges
