Product description The ComNet eConsole is a powerful network management Windows utility software suite including three powerful applications that can meet various demands for network monitoring and management in a wide range of industrial applications. It utilizes three key functions - Centralized Management, Visualized Management, and Device Monitoring. With advanced monitoring features and various warning systems, users can be informed of any accidental situations in the local network and recover the network immediately. This software suite comes with a USB License Key that supports up to 500 Ethernet switches. Compatible With - eConsole Applications (eCommander, eVision, and eMonitor)
-
- ValueLine Series CWGE24MS, CWGE26FX2TX24MSPOE, and CWGE28FX4TX24MS Switches
- Industrial CNGE5MS, CNGE2FE8MSPOE2, CNGE2FE8MSPOE+, CNGE3FE7MS3, CNGE8MS, CNGE12MS, CNGE20MS, CNGE24MS, CNGE28FX4TX24MS, and CNGE28FX4TX24MSPOE Switches
- Substation CNGE3FE7MS4 Switch
- eConsole Applications (eVision and eMonitor only)
-
- ValueLine Series CWGE9MS, CWGE2FE8MSPOE, CWGE2FE24MODMS, and CWGE24MODMS Switches
- Industrial CNGE2+2SMS[POE][HO], CNGE2FE8MSPOE, CNGE2FE16MS, CNGE3FE7MS2, CNGE8FX4TX4MS, CNGE2FE24MS, and CNGE2FE24MSPOE Switches
- eConsole eMonitor Application
-
- ValueLine Series CWFE8TX8MS and CWFE8MS/DIN Switches
eConsole Key Functions - Centralized Management
-
- Configure all ComNet Ethernet switches in the network at once in a few steps using application wizards such as IP setting group wizard, Firmware upgrade group wizard, and redundant ring (C-Ring) setting wizard
- Compatible managed switches no longer require individual configuration
- Visualized Management
-
- Topology View (eVision) can display the complex topologies of ComNet’s Ethernet switches in the local network
- Different switches can be grouped by different IPs and in different topology windows
- Health status of the connections will be displayed as different colors for quick visual reference
- ComNet Topology View helps the administrators to do the management visually, intuitively, and more efficiently
- Device Monitoring (eMonitor)
-
- eConsole has various mechanisms to monitor the ComNet switches, including an event log and SNMP traps
- Administrators can be informed of any abnormal events, and the event log can be exported as an Excel file
- Configuration of the switcher can be saved and the configurations of all switches in local network can be scanned regularly to detect any changes
- Administrators can be made aware of any unexpected changes to the configurations of the switches
- ComNet Host Monitor (eMonitor) can automatically ping and check the health statuses of connections among all IP-based devices in the local area network
- Host Monitor also features IP categorized function, and all IP-based devices can be monitored in groups of different IPs
eConsole Applications - eCommander
-
- Automatic device discovery
- Device status monitoring
- Syslog events
- Scan device configuration
- eVision
-
- Topology views show the topology of connections among all of the switches in the local network
- IP categorized function
- Configure the switches into different IP domains
- Visualized warning system of the health statuses of the connections among the switches
- Traffic flow analysis of each node
- Event log that can be exported as an Excel file
- Administrator can plan the future topology manually in the ‘Edit’ operation mode
- ComNet Map technology can show network device locations using Google Map Data for automatic device discovery, device status monitoring, syslog events, and scan device configuration
- eMonitor
-
- IP scan to detect all of the IP-based devices in the local network
- To check the health statuses of connections of all IP-based devices
- All of IP-based devices can be grouped and managed by different IP ranges
In the Box COMNET eConsole Powerful Network Management PC Utility Suite for ComNet Ethernet Switches (500 Switch License) eConsole Installation CD USB License Key for 500 Ethernet Switches Table of Contents
|
Upload User Manual
Have you got an user manual for the COMNET eConsole Powerful Network Management PC Utility Suite for ComNet Ethernet Switches in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersCOMNET ECONSOLE500 Specs | | | Operating System | Windows 2000/2003/XP/Vista/7 | | CPU | Intel Core 2 Duo 2.4 GHz | | RAM | 1 GB | | Hard Disk Space | 1 GB | | Browser | Internet Explorer 6.0 Service Pack V1 or higher |
