User Manual for Comprehensive Premium 2 Conductor Shielded Flexible Plenum Bulk Audio Cable Click to enlarge the picture
Contents of the user manual for the Comprehensive Premium 2 Conductor Shielded Flexible
- Product category: Bulk Audio Cable Comprehensive
- Brand: Comprehensive
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Comprehensive Bulk Audio Cable
|
User manual for the Comprehensive Premium 2 Conductor Shielded Flexible contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Comprehensive product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Comprehensive user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Comprehensive product will considerably shorten its lifespan!
|
Product description The black, 1,000’ Comprehensive Premium 2 Conductor Shielded Flexible Plenum Bulk Audio Cable is a twisted pair plenum cable that is made up of two #22 AWG bare copper wires and a #26 AWG tinned copper drain wire. This cable is suitable for all audio applications requiring a plenum cable. An overall shield of aluminum mylar foil provides 100% coverage. This cable has a UL rating of CL2P/CMP and can be used without conduit. The 22 gauge twisted pair is suitable for carrying audio signals for pro-audio, sound systems, and recording studios. It includes a ripcord and sequential foot markings to facilitate easy cable management and inventory control. - Two 22 AWG bare copper conductors
- Flexible black plenum jacket
- 1,000' put-up in an easy-pull box
UPC: 808447068924 In the Box Comprehensive Premium 2 Conductor Shielded Flexible Plenum Bulk Audio Cable (Black / Pull Box / 1,000') Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Comprehensive Premium 2 Conductor Shielded Flexible Plenum Bulk Audio Cable in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersComprehensive CVC-2TW/P-1000BPB Specs | Conductor | 2 | | Gauge | 22 AWG stranded bare copper | | Conductor | Conductor Colors: Black, Red | | Drain Wire | 26 AWG tinned copper | | Shield | 100% Aluminum mylar foil wrap | | Impedance | 55 Ω | | Capacitance | 25 between adjacent conductors
45 between conductors
Shield Nominal Velocity of Propagation: 69% | | Jacket | Flex-Plenum (black) | | UL Rating | CMP/FT6 | | Voltage Rating | 300 V | | Temperature Rating | 167°F (75°C) | | Length | 1,000.0' (304.8 m) | | Overall Diameter | 0.132" (3.352 mm) | | Weight | 15.0 lb (6.8 kg) | | | | Package Weight | 12.485 lb | | Box Dimensions (LxWxH) | 14.8 x 12.5 x 9.25" |
