Product description The black, 500’ Comprehensive Premium 2 Conductor Shielded Flexible Plenum Bulk Audio Cable is a twisted pair plenum cable that is made up of two #22 AWG bare copper wires and a #26 AWG tinned copper drain wire. This cable is suitable for all audio applications requiring a plenum cable. An overall shield of aluminum mylar foil provides 100% coverage. This cable has a UL rating of CL2P/CMP and can be used without conduit. The 22 gauge twisted pair is suitable for carrying audio signals for pro-audio, sound systems, and recording studios. It includes a ripcord and sequential foot markings to facilitate easy cable management and inventory control. - Two 22 AWG bare copper conductors
- Flexible black plenum jacket
UPC: 808447068917 In the Box Comprehensive Premium 2 Conductor Shielded Flexible Plenum Bulk Audio Cable (Black / Reel / 500') Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Comprehensive Premium 2 Conductor Shielded Flexible Plenum Bulk Audio Cable in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersComprehensive CVC-2TW/P-500BR Specs | Conductor | 2 | | Gauge | 22 AWG stranded bare copper | | Conductor | Conductor Colors: Black, Red | | Drain Wire | 26 AWG tinned copper | | Shield | 100% Aluminum mylar foil wrap | | Impedance | 55 Ω | | Capacitance | 25 between adjacent conductors
45 between conductors
Shield Nominal Velocity of Propagation: 69% | | Jacket | Flex-Plenum (black) | | UL Rating | CMP/FT6 | | Voltage Rating | 300 V | | Temperature Rating | 167°F (75°C) | | Length | 500.0' (152.4 m) | | Overall Diameter | 0.132" (3.352 mm) | | Weight | 8 lb (3.6 kg) | | | | Package Weight | 7.5 lb | | Box Dimensions (LxWxH) | 8.3 x 8.1 x 4.8" |
