Product description This Computar 1" 50mm f/1.4 2MP Lens is designed for cameras with a C-Mount for use in a variety of applications. It has a fixed focal length of 16mm, and resolves an image on 1" cameras with 2MP sensors. Featuring a minimum focus distance of 11.8", the lens focuses to infinity and incorporates both lockable iris and focus rings, so you can leave the lens set up and not have to worry about either ring changing over time. The front of the lens incorporates an M40.5 filter thread. - The fast f/1.4 aperture enables you to use this lens in low-light situations
- The lens works in temperatures from below freezing to over 100 degrees Fahrenheit
UPC: 781904053438 In the Box computar 1" 50mm f/1.4 2MP Lens (C-Mount) Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the computar 1" 50mm f 1.4 2MP Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameterscomputar V5014-MP Specs | Mount | C-Mount | | Focal Length | 50mm | | Focus Range | 1.64' to ∞ / 50 cm to ∞ | | Iris Range | f/1.4 to f/16 | | Coverage | 1" Type sensor
Max Image Format: 0.5 x 0.38" (0.63") / 12.8 x 9.6 mm (16 mm) | | Object Dimensions at M.O.D. | 1": 0.37 x 0.49" / 0.941 x 1.257 cm | | Effective Lens Aperture | Front Diameter: 1.38" / 35.00mm
Rear Diameter: 0.63" / 16.00mm | | Angle of View | 1": 18.03° (14.5 x 10.92°)
2/3": 12.49° (10.02 x 7.53°) | | Distortion | -0.82% (y=8.0) | | Back Focal Length | 0.57" / 14.55mm | | Flange Back Length | 0.69" / 17.526 mm | | Filter Size | M40.5
P=0.5 mm | | Operating Temperature | 14 to 113°F / -10 to 45°C | | Dimensions | Diameter x Length: 1.87 x 1.89" / 47.5 x 48 mm | | Weight | 6.7 oz / 190.0 g | | | | Package Weight | 0.45 lb | | Box Dimensions (LxWxH) | 3.5 x 2.3 x 2.2" |
