User Manual for Countryman Isomax DBM Stage Microphone Click to enlarge the picture
Contents of the user manual for the Countryman Isomax DBM Stage Microphone
- Product category: Hanging Microphones Countryman
- Brand: Countryman
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Countryman Hanging Microphones
|
User manual for the Countryman Isomax DBM Stage Microphone contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Countryman product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Countryman user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Countryman product will considerably shorten its lifespan!
|
Product description The Countryman Isomax DBM stage microphone incorporates Countryman's Isomax capsule and accessorizes with an adjustable stage mounting plate. The microphone is mounted on stage floors and can achieve great range without audience and background noise. A cable reel and 50-feet (15.24m) of specially constructed cable for reliable, clutter-free microphone placement is included.The microphone's design incorporates Countryman's dedication to high audio standards; with features that include a low-mass miniature capsule and back-plate polarization. The result yields a high transient response without distortion and a uniform frequency response at the direct and off-axis sections of the polar pattern. Fewer Isomax DBM microphones are needed to achieve maximum pickup and a full, rich sound.The Countryman DBM is a professional miniature surface mounted microphone that may be used as a stage microphone, podium microphone, plant microphone for motion picture and more. - Uniform Response
- The capsule's design results in a frequency independent, directional polar pattern. A rich, full sound is achieved with fewer microphones.
- Unobtrusive Design
- The miniature Isomax DBM features a miniature unobtrusive design. The microphone may be installed on stages while remaining out of view.
- Cable Reel
- The included reel 50-foot cable provides flexible clutter-free microphone placement and positioning.
In the Box Countryman Isomax DBM Miniature Surface Mounted Stage Microphone (Black) Adjustable Surface Mounting Plate 50-Foot (15.24m) XLR Cable with Reel 1 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Countryman Isomax DBM Stage Microphone in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersCountryman Isomax DBM Specs | Transducer | Condenser | | Polar Pattern | Hypercardioid | | Frequency Response | 40Hz to 18kHz (figure 1) | | Dynamic Range (Typical) | 101dB | | Signal-to-Noise Ratio | 65dB referred to 94dB SPL | | Maximum Input Sound Level | 130dB @ 1% THD 1kHz | | Power Requirements | Phantom 9V @ 1mA to 55V @ 8 mA | | Output Impedance | 350 ohms | | Output Connectors | 3-pin XLR | | Pad | No | | Low Frequency Roll-Off | No | | Dimensions | Not Specified By Manufacturer | | Weight | Not Specified By Manufacturer | | | | Package Weight | 1.0 lb | | Box Dimensions (LxWxH) | 10.0 x 10.0 x 2.0" |
