User Manual for Cubix Linux2U Rackmount Elite Click to enlarge the picture
Contents of the user manual for the Cubix Linux2U Rackmount Elite
- Product category: PC Workstations Cubix
- Brand: Cubix
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Cubix PC Workstations
|
User manual for the Cubix Linux2U Rackmount Elite contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Cubix product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Cubix user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Cubix product will considerably shorten its lifespan!
|
Product description The Cubix Linux2U Rackmount Elite consists of the HostEngine 2U Computer which is connected to the Xpander Rackmount Elite 4U PCIe Enclosure. The Xpander Rackmount Elite is designed for the broadcast industry digital cinema production environments, and visualization projects which require plenty of additional power and PCIe slots, while maintaining a small physical footprint and quiet operation. Using only one PCIe x16 slot in the host PC or Mac Pro, Xpander Rackmount Elite provides you with six additional full-length, full-height PCIe slots for use with multiple NVIDIA graphics cards, SDI capture cards from Blackmagic Design, AJA, Bluefish444, NVIDIA, and others. You can add multiple RED Rocket cards, high-performance NVIDIA Quadro graphics by PNY, as well as fiber optic HBAs, RAID controllers, PCIe-based memory cache cards. It comes equipped with one AMD FirePro W2100 and two NVIDIA GTX 980 graphics cards. The HostEngine 2U comes with 16GB of RAM and one 500GB SATA3 SSD, but supports up to 1TB of RAM and a 2TB SATA3 SSD. It has four PCIe x16 (gen 3) expansion slots for low-profile cards such as the Cubix HIC that connects to Xpander. The system is loaded with CentOS Linux 6.4 and Cubix GPU Manager to monitor the health and performance of both the GPUs and Xpander. Note: Customers / end users must add their own Blackmagic Design DaVinci Resolve 11 license key - XPRM-G3-ELRHE 4U 19" Gen3 Xpander Rackmount Elite (1500W, External) The 1500W, external XPRM-G3-ELRHE 4U 19" Gen3 Xpander Rackmount Elite from Cubix is a 4RU, PCIe expansion chassis. It can support one server/workstation connection with up to four 16-channel PCIe Gen3 high-performance dual slot cards plus two single slot 8-channel I/O cards per system. It provides a high-bandwidth external slot array for applications ranging from NVIDIA Quadro SVS to onset production applications, in media and entertainment. The Gen3 Xpander supports up to sixteen hard drives or DCI 2K projectors, or up to four 4K (or UltraHD) monitors and projectors via NVIDIA SVS and G-Sync III. This system includes a 4-channel slot (power only) for use with the NVIDIA G-Sync III card in high-end visualization applications.
- You can install four dual slot GPUs (Graphical Processing Units) for hardware acceleration purposes as well as other types of third party I/O controllers
- Four PCIe Gen 3 x16 expansion slots (supporting both dual slot and single slot cards) and two 8-channel slots (supports single slot cards) per MIB (Main Interface Board), total of six slots per system
- One MIBs per 4RU, 19" rack mount system (one PCIe backplane, one 16-channel data cable, and one 16-channel HIC)
- An independent 1500W power supply and cooling fan to meet expansion requirements
- Simple, quick installation with minimal impact per rackmount computer. Install a HIC (Host Interface Card) and drivers for installation of devices in GPU-Xpander
- Each x16 cable and connector provides a 250 mating duty cycle (purchase additional x16 HICs for sharing with multiple host computers)
- Hardware-acceleration using NVIDIA graphics and GPU cards for application acceleration
- Enhances server I/O infrastructure capabilities without adding servers
Benefits - Adds four dual slot GPUs for supporting rackmount computers, which have limited slot expansion capabilities and limited power supply capacities
- Supports one host PC or Apple Mac Pro workstation with one Xpander Rackmount Elite
Applications - DaVinci Resolve Win/Linux, Autodesk 3ds Max, Flame, Smoke, Chaos Group V-Ray, Assimilate Scratch, rendering, Fusion-io SSDs, NVIDIA Quadro SVS, on-set apps
- HostEngine Rackmount Computer for GPU Xpander Systems (2 RU)
In the Box Bundle Items XPRM-G3-ELRHE 4U 19" Gen3 Xpander Rackmount Elite (1500W, External) vrvfccyebdzsuzyxdbtyrfs - 16-Channel Host Interface Card
HostEngine Rackmount Computer for GPU Xpander Systems (2 RU) Table of Contents
|
Upload User Manual
Have you got an user manual for the Cubix Linux2U Rackmount Elite in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - XPRM-G3-ELRHE 4U 19" Gen3 Xpander Rackmount Elite (1500W, External)
| Rackmount | 4U, 19" | | Number of PCIe Expansion Slots | 6 | | Number of Graphics Cards Supported | 4 x Dual slot x16
2 x Single slot x8 | | Number of Workstations Supported | Maximum: 1 | | Number of PCIe Channels | 16 and 8 | | Transfer Rate | 128 Gb/s + 80 Gb/s (Gen3) | | Power Supply | 1500 W | | Fans | 3 x QF fans (variable speed, temperature-controlled exhaust fans) | | Weight | 46.0 lb (20.8 kg) | - HostEngine Rackmount Computer for GPU Xpander Systems (2 RU)
