User Manual for CyberPower RKBS15S4F12R 16-Outlet Rackbar Surge Suppressor Click to enlarge the picture
Contents of the user manual for the CyberPower RKBS15S4F12R 16-Outlet Rackbar Surge Suppressor
- Product category: Power Strips CyberPower
- Brand: CyberPower
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for CyberPower Power Strips
|
User manual for the CyberPower RKBS15S4F12R 16-Outlet Rackbar Surge Suppressor contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any CyberPower product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official CyberPower user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a CyberPower product will considerably shorten its lifespan!
|
Product description The RKBS15S4F12R 16-Outlet Rackbar Surge Suppressor from CyperPower provides 120V 15A output and a surge suppression rating of 3600 joules. It distributes power to 16 NEMA 5-15R receptacles from a single NEMA 5-15P plug. Designed for datacenters and other electrically demanding applications, this unit has a rugged, industrial-grade metal housing and a 15-foot AC power cord. It can be mounted either horizontally or vertically, includes a cord retention tray, and is ETL/RoHS certified. A lifetime warranty and $150,000 Connected Equipment Guarantee ensures the Rackbar Surge Suppressor is free of defects in design, assembly, material, or workmanship. UPC: 649532901715 In the Box CyberPower RKBS15S4F12R 16-Outlet Rackbar Surge Suppressor Limited Lifetime Manufacturer Warranty More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the CyberPower RKBS15S4F12R 16-Outlet Rackbar Surge Suppressor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersCyberPower RKBS15S4F12R Specs | | | Voltage | 120 V | | Frequency | 50 / 60 Hz | | Maximum Input Current | 15 A | | Plug Type | NEMA 5-15P | | Plug Style | Straight | | Cord Length | 15' / 4.6 m | | | | Nominal Output Voltage | 120 V | | Outlets | Total: 16 (4 x front, 12 x rear) | | Outlet Type | NEMA 5-15R | | LED Indicators | Power on (green), Grounded (green) | | Overload Protection | 15 A | | | | Surge Supression | 3600 Joules | | Protection Modes | N-H, N-G, and H-G | | Maximum Surge Current | 105,000 A | | Maximum Surge Voltage | 6000 V | | Clamping Voltage | 400 V (N-H, N-G, H-G) | | Response Time | 1 nanosecond | | EMI/RFI Filtration | Yes | | Attenuation | Up to 50 dB | | | | Operating Temperature | 32 to 95°F / 0 to 35°C | | Operating Humidity | 0 to 95% non-condensing | | Storage Temperature | 5 to 113°F / -15 to 45°C | | Maximum Operating Elevation | 10,000 ft / 3,000 m | | Maximum Storage Elevation | 50,000 ft / 15,000 m | | | | Safety | UL1363 UL1449 certified by ETL (USA), CSA C22.2 (Canada) | | Environmental | RoHS compliant | | | | Connected Equipment Guarantee | Lifetime | | CEG Amount | $150,000 | | | | Rack Size | 1U | | Form Factors Supported | 1U rackmount, 0U vertical rackmount, undercounter installation supported | | Style | Rackmount, vertical rackmount, under-counter | | Cord Retention Tray / Cord Organizers | Yes | | External Site Ground Pin | Yes | | Material of Construction | Metal | | Adjustable Mounting Brackets | 2 sets (L-short, L-long) | | Dimensions | 1.75 x 17.50 x 2.25" / 4.45 x 44.45 x 5.72 cm | | Weight | 4.16 lb / 1.89 kg |
