Product description The Lite Series 2MP Outdoor HDCVI Eyeball Camera from Hikvision utilizes a 1/2.9" CMOS image sensor and 2.7 to 13.5 varifocal lens to capture images of 1920 x 1280 resolution at 30 fps. The camera offers day/night functionality thanks to its ICR and IR LEDs that are effective up to 98'. The camera offers a multi-language on-screen display and HD and SD dual-output. It is protected against water and dust with an IP67-rated case, making it suitable for indoor or outdoor environments. - Three Signals over a Single Coaxial Cable
- HD-CVI technology simultaneously transmits video, power, and data over a single coaxial cable. Dual-way data transmission allows the camera to communicate with an HCVR to send control signals or to trigger alarms.
- Long-Distance Transmission
- HD-CVI technology guarantees real-time transmission over long distances without loss of video quality. HD-CVI cameras provide the same resolution as most IP network camera systems using existing RG-59, RG-6, or Cat 6 UTP cabling with a balun (available separately).
- Smart IR
- With IR illumination, detailed images can be captured in low light or total darkness. The camera's Smart IR technology adjusts the intensity of the camera's infrared LEDs to compensate for the distance of an object.
- Multi-Format Support
- The camera supports multiple video formats including, HD-CVI, CVBS, AHD, and TVI. The camera can switch between these four formats via the OSD menu or via a UTC controller (PFM820), making the camera compatible with HD-CVI DVRs.
- Multi-Language OSD
- The OSD menu provides multiple image adjustment and function settings to meet the requirements of different scenes. The OSD menu includes configurations such as backlight mode, day/night, white balance, privacy masking, and motion detection and offers Chinese, English, French, German, Spanish, Italian, Japanese, Korean, Russian, Polish, and Portuguese variations.
- Protection
- The camera is protected against water and dust with an IP67-rated case, making it suitable for indoor or outdoor environments. With a built-in heater and a working temperature range of -40 to 140°F, the camera is designed for extreme temperature environments. Supporting
|
Upload User Manual
Have you got an user manual for the Dahua Technology Lite Series 2MP Outdoor HDCVI Eyeball Camera with Night Vision & 2.7-13.5mm Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDahua Technology Lite Series Specs | | | Image Sensor | 1/2.9" CMOS | | Effective Pixels | 1920 x 1280, 2 MP | | Scanning System | Progressive | | Electronic Shutter Speed | 1/1,00,000 to 1/3 seconds | | Minimum Illumination | Color: 0.02 lux at f/1.3
0 lux (with IR on) | | S/N Ratio | More than 65 dB | | IR Range | Up to 98' / 30 m | | IR Control | Auto, manual | | IR LEDs | 20 | | | | Lens Type | Varifocal | | Mount Type | Board-in | | Focal Length | 2.7-13.5mm | | Maximum Aperture | f/1.3 | | Horizontal Angle of View | 104 to 27° | | Focus Control | Manual | | Close Focus Distance | 7.87" / 200 mm | | | | Range | Pan: 0 to 360°
Tilt: 0 to 90°
Rotation: 0 to 360° | | | | Resolution | 1080p (1920 x 1080) | | Frame Rate | 1080p at 30 fps
720p at 30/60 fps | | Video Output | 1 x BNC HD-CVI high-definition channel, or
1 x BNC CVBS, AHD, or TVI channel, switchable | | Maximum Video Transmission Range | RG-59/U Coax:
720p: 2624.7' / 800 m
1080p: 1640.4' / 500 m
RG-6/U Coax:
720p: 3937' / 1200 m
1080p: 2624' / 800 m
Cat 6 UTP (Balun Required):
720p: 1476' / 450 m
1080p: 984' / 300 m | | Day/Night | Auto (ICR), manual | | OSD Menu | Multi-language | | BLC | BLC, HLC, DWDR | | WDR Control | Digital WDR | | Gain Control | AGC | | Noise Reduction | 2D | | White Balance | Auto, manual | | Smart IR | Auto, manual | | | | Safety | EN55032, EN55024, EN50130-4
UL60950-1+CAN/CSA C22.2 No.60950-1 | | EMC | FCC CFR 47 FCC Part 15 Subpart B
ANSI C63.4-2014 | | | | Power Supply | 12 VDC
