Dahua Technology Mobile Series DH-IPC-HDBW4431FN-M12 4MP

User Manual for Dahua Technology Mobile Series DH-IPC-HDBW4431FN-M12 4MP Outdoor Network Wedge Camera with 3.6mm Lens & Night Vision

• Product category: Wired IP Cameras Dahua Technology
• Brand: Dahua Technology
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Dahua Technology Wired IP Cameras

Product description

• 1/3" 4MP progressive scan CMOS sensor

• Up to 2688 x 1520 resolution at 30 fps

• H.265+, H.265, H.264+, H.264, and MJPEG video compression for efficient bandwidth and storage use

• Triple-stream encoding

• 3.6mm fixed lens

• 16x digital zoom

• 0°, 90°, 180°, and 270° flip

• IR LEDs for night vision up to 65'

• Smart IR for uniform brightness in B&W images under low illumination; LED intensity adjusts in proportion to object distance, preventing overexposure as objects move closer to camera

• microSD card slot for edge storage supports up to 128GB (microSD card available separately)

• 120 dB wide dynamic range

• Built-in IVS video analytics including Tripwire violation detection, intrusion detection, abandoned object detection, missing object detection, face detection, tamper detection, sudden scene change detection

• 3D-DNR digital noise reduction technology

• 512MB RAM and 32MB ROM memory

• ONVIF compliant

• Certified EN 50155 and E-mark (ECE regulation no. 10) for mobile applications

• Broad operating temperature range of -22 to 140°F

• ±30% input voltage tolerance

• 6kV lightning protection

• IP67 rated for outdoor use

• IK10-rated vandal resistance

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

Dahua Technology DH-IPC-HDBW4431FN-M12 3.6MM Specs

Recording Media	microSD (Up to 128 GB)
Pan/Tilt	None
I/O Connections	1 x M12
IR Illuminators	None
IR Range	65.62' / 20 m
Video Management Software	IVS, Smart PSS, DSS
Certifications	FCC (Part 15 Class B), UL, as per Manufacturer
Internal Storage	None
External Storage Options	Local PC, NAS
Power Source	DC, PoE 802.3af (15 W)
Power Consumption	4.5 W
Material of Construction	Metal (Unspecified Type)
Operating Temperature	-22 to 140°F / -30 to 60°C
Storage Temperature	-22 to 140°F / -30 to 60°C
Operating Humidity	95%
IP Rating	IP67
IK Rating	IK10
