User Manual for Dahua Technology PFM700 HDMI Extender Click to enlarge the picture
Contents of the user manual for the Dahua Technology PFM700 HDMI Extender
- Product category: Signal Extenders Dahua Technology
- Brand: Dahua Technology
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Dahua Technology Signal Extenders
|
User manual for the Dahua Technology PFM700 HDMI Extender contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Dahua Technology product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Dahua Technology user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Dahua Technology product will considerably shorten its lifespan!
|
Product description Quickly extend the reach of HDMI cables with the PFM700 HDMI Extender from Dahua Technology using an Ethernet cable. The transmitter and receiver work together to extend HDMI signals over a single Ethernet cable, allowing you to connect an external monitor up to 197' away from a video source. Anti-thunder, anti-static, and anti-interference capabilities are included to ensure high-quality signal protection and transmission. - Extends HDMI signals up to 197'
- Anti-thunder, anti-static, and anti-interference capabilities
- Supports Cat5e and Cat6 UTP cable
- Supports HDMI 1.3 and lower
UPC: 816116023235 In the Box Dahua Technology PFM700 HDMI Extender Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Dahua Technology PFM700 HDMI Extender in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDahua Technology PFM700-E Specs | Transmission Type | 1 channel, HDMI | | Transmission Distance | Up to 197' (60 m) | | Video Signal Input | HDMI | | Ethernet | RJ45 port
Cat5e or Cat6 UTP cable | | Input Voltage | 5 VDC | | Power | Transmitter: <3 w
Receiver: <3 W | | HDCP Support | HDCP 1.2 | | HDMI Support | HDMI 1.3 and lower | | Resolution | 1080p, 1080i, 720p, 576p, 576i, 480p, 480i | | Output Voltage | 0.5-1.5 V p-p | | Protection | ESD:
IEC61000-4-2 1995 (GB/T 17626.5)
Contact Discharge Electricity Level: 3
Air Discharge Electricity Level: 3
Anti-Thunder:
1 kV, IEC6100-4-5 1995 (GB/T 17626.5) | | Mean Time Before Failure | >5000 hours | | Material | Shell: Aluminum | | Operating Temperature | 32 to 131°F (0 to 55°C) | | Storage Temperature | -4 to 176°F (-20 to 80°C) | | Humidity | 0 to 95%, non-condensing | | Dimensions | Transmitter: 3.5 x 2.5 x 0.98" (88 x 64 x 25 mm)
Receiver: 3.5 x 2.5 x 0.98" (88 x 64 x 25 mm) | | Weight | Transmitter: 3.4 oz (97 g)
Receiver: 3.2 oz (91 g) | | | | Package Weight | 1.05 lb | | Box Dimensions (LxWxH) | 8.6 x 5.1 x 2.0" |
