User Manual for Dahua Technology Pro Series C52A2N 8-Channel Tribrid 8MP DVR with 8TB Click to enlarge the picture
Contents of the user manual for the Dahua Technology Pro Series C52A2N 8-Channel
- Product category: Digital Video Recorders (DVRs) Dahua Technology
- Brand: Dahua Technology
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Dahua Technology Digital Video Recorders (DVRs)
|
User manual for the Dahua Technology Pro Series C52A2N 8-Channel contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Dahua Technology product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Dahua Technology user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Dahua Technology product will considerably shorten its lifespan!
|
Product description Record video from HD-CVI, CVBS, or IP cameras with the Pro Series C52A2N 8-Channel Tribrid 8MP DVR with 8TB from Dahua Technology. This DVR supports up to 12 cameras (8 analog & 4 IP) at up to 3840 x 2160 resolution. It comes equipped with two SATA ports that support up to 8TB HDD capacity per disk, for a maximum of 16TB (8TB HDD preinstalled). Smart H.264+ and H.264 video compression ensure high-quality recording and playback.
This NVR supports up to 128 users. An RCA audio I/O makes two-way talk possible. HDMI and VGA video outputs enable users to connect a monitor (available separately) to view a live feed locally. ONVIF compliance for version 2.4.1 offers interoperability with ONVIF IP cameras. - Embedded processor and Linux OS
- Up to 8MP recording resolution for high-quality playback
- Supports HD-CVI, CVBS, and IP cameras
- HCVR technology offers flexible recording options
- Smart H.264+ and H.264 dual stream compression
- HD-CVI and CVBS auto-detect functionality recognizes connected cameras
- Spot output enables an operator to view a secondary monitor (available separately) assigned to selected cameras or video inputs
- Motion detection and scheduled recording helps to reduce storage requirements
- Built-in Smart Search makes searching for specific videos quicker and easier
- Intelligent Video System (IVS)
- IVS triggers an alarm and take a defined action for the following events:
- Tampering with the camera
- Memory card error
- Network error
- Unauthorized access
- Motion detection
- Tripwire
- Intrusion detection
- Scene change detection
- Abandoned/missing object detection
UPC: 819290025361 In the Box Dahua Technology Pro Series C52A2N 8-Channel Tribrid 8MP DVR with 8TB Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Dahua Technology Pro Series C52A2N 8-Channel Tribrid 8MP DVR with 8TB in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDahua Technology C52A2N Specs | | | Main Processor | Embedded processor | | Operating System | Embedded Linux | | | | Interface | 1 x HDMI (up to 3840 x 2160)
1 x VGA | | Spot Output | HDMI or VGA (configurable) | | Resolution | 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768 | | Multi-Screen Display | 1/4/8/9/16 | | On-Screen Display | Camera title, time, video loss, camera lock, motion detection, and recording | | | | Event Trigger | Recording, PTZ, tour, alarm out, video push, email, FTP, snapshot, buzzer, and screen tips | | Video Detection | Motion detection
MD Zones: 396 (22 x 18), video loss, tampering, and diagnosis | | | | Playback | 1/4/9 | | Search Modes | Time/date, alarm, motion detection, and exact search (accurate to 1 sec) | | Playback Function | Play, pause, stop, rewind, fast play, slow play, next file, previous file, next camera, previous camera, full screen, repeat, shuffle, backup selection, and digital zoom | | Backup Modes | USB device, network | | | | Internal HDD | 8 TB preinstalled, 16 TB (2 x 8 TB) | | HDD Mode | Single | | | | USB | 1 x USB 2.0
1 x USB 3.0 | | RS-485 | 1 RS-485 port for PTZ control | | | | Compatible Brands | Dahua, Arecont Vision, Axis, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and others | | | | Analog Inputs | 8
Up to 8 MP resolution for the first channel | | IP Camera Inputs | 8 + 4
Up to 8 MP resolution per channel | | Audio I/O | 1/1 | | Two-Way Talk | Reuse audio I/O, RCA | | | | Compression | Smart H.264+, H.264 | | Resolution | 8 MP (4K), 4 MP, 1080p, 720p, 960H, D1, HD1, BCIF, CIF, QCIF | | Recording Rate | Main Stream:
First Channel: 8 MP (4K) at 15 fps or 4 MP at 15 fps
Other Channels: 4 MP at 15 fps or 1080p, 720p, 960H, D1, HD1, BCIF, CIF, QCIF at 30 fps
Sub Stream: D1, CIF, QCIF at 30 fps | | Bit Rate | 1 to 12,288 kb/s per channel | | Recording Modes | Manual, schedule (regular, continuous), motion detection (video detection includes motion detection, video loss & tampering), alarm, and stop | | Record Time | 1 to 60 min (default 60 minutes)
Pre-Record: 1 to 30 seconds
Post-Record: 10 to 300 seconds | | | | Interface | 1 x 1000M RJ45 port | | Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP filter, PPPoE, DDNS, FTP, alarm server, P2P, IP search (supports Dahua IP camera, DVR, NVS) | | Maximum User Access | 128 users | | Mobile OS Support | iOS and Android | | Interoperability | ONVIF 2.4.1, CGI conformant | | | | Power Supply | 12 VDC, 4 A | | Power Consumption | <15 W without HDD | | Operating Temperature | 14 to 131°F / -10 to 55°C | | Operating Humidity | 0 to 90% RH | | Storage Temperature | -4 to 158°F / -20 to 70°C | | Storage Humidity | 0 to 90% RH | | Installation | Desktop installation | | Certifications | Safety: UL 60950-1, CAN/CSA C22.2 No. 60950-1-07
Electromagnetic Compatibility (EMC): FCC Part 15 Subpart B ICES 003 Issue 6, EN 55032: 2012+AC:2013 (Class B), EN 50130-4: 2011, EN 61000-3-2: 2014, EN 61000-3-3: 2013
Immunity: EN 55024: 2010 | | Rack Units | 1 RU | | Dimensions | 14.8 x 11.3 x 2.1" / 375 x 287 x 53 mm | | Weight | 5.2 lb / 2.35 kg without HDD |
