Product description Monitor up to four outdoor areas with the Wi-Fi Series 4-Channel 5MP NVR with 1TB HDD and 4 3MP Outdoor Wi-Fi Night Vision Bullet Cameras from Dahua Technology. This Kit contains everything you need for a complete surveillance setup, including a 4-channel Wi-Fi NVR, an uninstalled 1TB HDD to store video, four outdoor Wi-Fi bullet cameras, and four power adapters to power the cameras. - Dahua Technology Wi-Fi Series 4-Channel 5MP 1U NVR (No HDD) Connect up to four cameras to the Wi-Fi Series 4-Channel 5MP 1U NVR from Dahua Technology for wireless video storage and security monitoring. This NVR features three external antennas to provide long signal range to connected cameras. It operates on the 2.4 or 5 GHz frequency and has the Smart Add feature, which allows the NVR to automatically scan the Wi-Fi network for available cameras and connect to them. Able to record up to 5MP video, this NVR compresses video using H.264 and MJPEG codecs for high-quality recording and playback while optimizing bandwidth. Additionally, connect up to two monitors (available separately) to the back of the NVR for simultaneous HDMI and VGA video output.
- Up to 5MP recording resolution for high-quality playback
- Wi-Fi connectivity for quick setup and easy maintenance
- Smart Add functionality automatically finds available Wi-Fi cameras on your network and connects them to the NVR
- Dual-core processor for up to 80 Mbps incoming bandwidth
- Simultaneous HDMI and VGA video output
- Three antennas for increased Wi-Fi range
- Automatic Network Replenishment (ANR) technology ensures no video transmission data is lost by storing temporary video data to a camera's memory card
- Watermarks can be placed on recorded video
- Wireless Access Point (WAP) functionality to expand your home Wi-Fi network
UPC: 816116025840 - 4 x Dahua Technology Lite Series N41BD12-W 4MP Outdoor Wi-Fi Network Bullet Camera with Night Vision The Lite Series N41BD12-W 4MP Outdoor Wi-Fi Network Bullet Camera with Night Vision from Dahua Technology uses a 1/3" progressive scan CMOS sensor to capture 2560 x 1440 resolution video at 20 fps. Eighteen IR LEDs provide up to 98' of night vision. The 2.8mm fixed lens delivers a 106° horizontal field of view. This Wi-Fi camera is equipped with a 10/100M Ethernet port. An onboard memory card slot supports microSD cards up to 128GB. microSD cards are available separately.
This device is housed in an IP67-rated metal and plastic enclosure that is suitable for outdoor use. - IEEE 802.11a/b/g/n/ac wireless standard
- Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG video compression
- Unicast and multicast streaming methods
- IR cut filter for true day and night functionality
- Auto and manual IR on/off control
- Backlight compensation, highlight compensation, and digital wide dynamic range
- Camera pivots horizontally from 0 to 360° & vertically from 0 to 90°
- White balance modes include auto, natural, street lamp, outdoor, and manual
- Auto and manual gain control
- Motion detection for 4 zones (rectangular)
- ROI (region of interest) for 4 zones
- Privacy masking for 4 areas (rectangular)
- Flip for 0, 90, 180, and 270°
- Compatible with Internet Explorer, Chrome, Firefox, Safari, iOS, and Android
- NAS, local PC for instant recording, and microSD card (up to 128GB) edge storage
- IP67-rated metal and plastic enclosure that is suitable for outdoor use
- 2kV lightning protection and ±10% input voltage tolerance
- DORI Distance
-
- 207' / 63m (detect / 8 ppf)
- 82' / 25m (observe / 19 ppf)
- 43' / 13m (recognize / 38 ppf)
- 20' / 6m (identify / 76 ppf)
UPC: 819290024982 - 4 x EverFocus 12 VDC Slim Line Power Adapter The EverFocus 12 VDC Slim Line Power Adapter can be used to supply 12 VDC power to a single CCTV camera. UPC: 697101008303
- WD 1TB Purple 5400 rpm SATA III 3.5" Internal Surveillance HDD Retail Kit The 1TB Purple 5400 rpm SATA III 3.5" Internal Surveillance HDD Retail Kit from Western Digital is a 3.5" SATA drive with a data transfer rate of 6 Gb/s that is designed to withstand the stresses placed on it in a 24/7 surveillance system. With support for up to 32 high-definition surveillance cameras, this 1TB hard drive can hold a large amount of data and gives you the ability to easily upgrade and expand your security system.
A 64MB cache helps to ensure uninterrupted data transfers and the drive's 300,000 load/unload cycles, combined with its 1 million hours MTBF helps ensure the drive will have a strong operational life. This drive is compatible with both Windows and Macintosh operating systems and includes mounting screws. - Surveillance-Class Drive
- WD Purple surveillance-class storage has been tested to be compatible in a wide-range of security systems. These drives are designed to replace standard desktop drives that were not designed for the 24/7 always-on, high-definition surveillance environment. Desktop drives are built to run for only short intervals and are not engineered to withstand high-temperature fluctuations and equipment vibrations found in a typical surveillance application.
- Surveillance Storage
- The WD Purple Surveillance Hard Drive is designed for high temperature, always-on, surveillance security systems to ensure reliability and quality video play back when you need it most.
- Improve Performance with AllFrame
- This WD Purple Surveillance-class hard drive is equipped with AllFrame technology which works with ATA streaming to reduce frame loss, improve playback and increase the number of drive bays supported. AllFrame reduces video interruptions that commonly occur when desktop hard drives are incorrectly used as storage in security systems. Missed frames and lost footage can be a problem when an event occurs and surveillance footage needs to be retrieved. WD Purple with AllFrame provides the confidence you should expect when it's time to play back and review critical surveillance footage.
- Optimized Performance for Up to 32 Cameras
- With support for up to 32 high-definition surveillance cameras, this WD Purple hard drive gives you the flexibility to upgrade and expand your security system in the future.
- IntelliPower Rotational Speed
- In terms of speed, this drive operates using WD's IntelliPower rotational speed. This means that the rpm speed of the drive depends on the operations being performed. If the drive is performing mostly sequential reads and writes, its speed will be increased as compared to if it were performing mostly random mode operations. This 6TB drive also features a 64MB cache helps ensure uninterrupted data transfers.
- Low Power Consumption
- With integrated IntelliSeek technology, this WD Purple drive calculates the optimum seek speed which lowers power consumption, noise and vibration that can damage and cause drives to wear out more quickly.
- Windows and Mac Compatible
- Compatible with Windows 8, 7, Vista, and XP
Compatible with Mac OS X Mountain Lion, Lion, and Snow Leopard
Please bear in mind that Windows XP does not support drives with capacities greater than 2TB. Compatibility may vary depending on user's hardware configuration and operating system - 1 million hours MTBF
- 1 million hours mean time between drive failures
UPC: 718037828701 In the Box - Wi-Fi Series 4-Channel 5MP 1U NVR (No HDD) deeyvsqusaeytxuc
- Power Cable
- USB Mouse
- IR Remote
- HDMI Cable
- Cat5 Network Cable
- SATA Cable
- Limited 3-Year Warranty
- 4 x Lite Series N41BD12-W 4MP Outdoor Wi-Fi Network Bullet Camera with Night Vision
- 4 x EverFocus - 12 VDC Slim Line Power Adapter
- WD - 1TB Purple 5400 rpm SATA III 3.5" Internal Surveillance HDD Retail Kit
Table of Contents
|
Upload User Manual
Have you got an user manual for the Dahua Technology Wi-Fi Series 4-Channel 5MP NVR with 1TB HDD & 4 3MP Outdoor Wi-Fi Night Vision Bullet Cameras in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - Dahua Technology Wi-Fi Series 4-Channel 5MP 1U NVR (No HDD)
| | | Processor | Dual-core embedded processor | | Operating System | Embedded Linux | | | | Interface | HDMI and VGA | | Resolution | 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768 | | Screen Display | 1, 4 | | On-Screen Display | Camera title, time, video loss, camera lock, motion detection, recording | | | | Event Trigger | Recording, PTZ, tour, video push, email, FTP, snapshot, buzzer, and screen tips | | Video Detection | Motion detection, MD zones (396 at 22 × 18), video loss, and camera blank | | | | Playback | 1, 4 | | Search Modes | Time/date, MD, and exact search (accurate to one second), Smart Search | | Playback Function | Play, pause, stop, rewind, fast play, slow play, next file, previous file, next camera, previous camera, full screen, repeat, shuffle, backup selection, digital zoom | | Backup | Via USB device or network | | | | Interface | 1 x SATA III port | | Capacity | Supports up to 6 TB | | | | Video | 4 x channels | | Auxiliary | 2 x USB 2.0 ports | | | | Support | Dahua, Arecont Vision, Axis, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and others | | | | Compression | H.264 and MJPEG | | Resolution | 5 MP, 4 MP, 3 MP, 1080p, 1.3 MP, 720p | | Maximum Bandwidth | 80 Mbps | | Bit Rate | 16 kbps to 20 Mbps per channel | | Recording Mode | Manual, schedule (regular, continuous), MD (Video Detection: motion detection, camera blank, video loss), stop | | Record Time | 1 to 120 min (Default: 60 min)
Pre-Record: 1 to 30 sec
Post-Record: 10 to 300 sec | | | | Connectivity | Wi-Fi, dual-band 2.4 and 5 GHz | | Interface | 1 x RJ45 10/100 Mbps Ethernet port | | Protocols | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP filter, PPPoE, DDNS, FTP, IP search (supports Dahua IP cameras, DVRs, NVS) | | Users | 128 users | | Mobile OS Support | iOS and Android | | Interoperability | ONVIF 2.4, CGI | | | | Power Supply | 12 VDC, 2 A | | Power Consumption | <10 W without HDD | | Operating Temperature | 14 to 131°F (-10 to 55°C) | | Pressure Level | 86 to 106 kPa | | Storage Temperature | -4 to 158°F (-20 to 70°C) | | Storage Humidity | 0 to 90% RH | | Dimensions | 10.2 x 9.7 x 1.9" (260 x 246.4 x 47.6 mm) | | Weight | 1.1 lb (0.5 kg) | | | | Box Dimensions (LxWxH) | 14.8 x 12.2 x 4.6" | - 4 x Dahua Technology Lite Series N41BD12-W 4MP Outdoor Wi-Fi Network Bullet Camera with Night Vision
| | | Image Sensor | 1/3" 4 MP progressive scan CMOS | | Effective Pixels (H x V) | 2688 x 1520 | | RAM | 512 MB | | ROM | 32 MB | | Electronic Shutter Speed | 1/100,000 to 1 sec (auto, manual) | | Minimum Illumination | Color: 0.53 lux at f/2.0 (1 sec, 30 IRE)
B&W: 0 lux at f/2.0 with IR on | | S/N Ratio | More than 50 dB | | IR Range | Up to 98.04' / 30 m | | IR Control | Auto and manual IR on/off control | | Number of IR LEDs | 18 | | | | Lens Type | Fixed | | Mount Type | Board-in | | Focal Length | 2.8mm | | Maximum Aperture | f/2.0 | | Field of View | Horizontal: 106°
Vertical: 56°
Diagonal: 127° | | Focus Control | Fixed | | | | Range | Horizontal: 0 to 360°
Vertical: 0 to 90°
Rotation: 0 to 360° | | | | Compression | Smart H.265+, H.265, Smart H.264+, H.264, MJPEG | | Streaming Capability | Two streams | | Resolutions | 4 MP (2560 x 1440), 3 MP (2304 x 1296), 1080p (1920 x 1080), SXGA (1280 x 1024), 1.3 MP (1280 x 960), 720p (1280 x 720), VGA (640 x 480), QVGA (320 x 240) | | Frame Rates | Main Stream:
4 MP at 20 fps
3 MP, 1080p, 1.3 MP, and 720p at 30 fps
Sub Stream:
VGA or QVGA at 30 fps | | Bit Rate Control | CBR, VBR | | Bit Rate | H.265: 9 to 8448 kb/s | | Day/Night | Auto IR cut filter, color, B&W | | Backlight Compensation | Digital WDR, BLC, HLC | | White Balance | Auto, natural, street lamp, outdoor, manual | | Gain Control | Auto, manual | | Noise Reduction | 3D-DNR | | Motion Detection | 4 zones, rectangular (off, on) | | Region of Interest | 4 zones (off, on) | | Smart IR | Supported | | Digital Zoom | 16x | | Flip | 0, 90, 180, and 270° | | Mirror | Off, on | | Privacy Masking | 4 areas, rectangular (off, on) | | | | Ethernet | RJ45, 10/100M | | Wi-Fi Connectivity | 2.4 GHz, IEEE 802.11a/b/g/n/ac | | Protocols | HTTP, HTTPS, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, QoS, UPnP, NTP, Bonjour, 802.1x, Multicast, ICMP, IGMP | | Interoperability | ONVIF, PSIA, CGI | | Streaming Method | Unicast and multicast | | Maximum User Access | 10 / 20 users | | Edge Storage | NAS, local PC for instant recording, and microSD card slot (maximum 128 GB, available separately) | | Web Viewer | Internet Explorer, Chrome, Firefox, Safari | | Management Software | Smart PSS, DSS | | Mobile OS Support | iOS, Android | | | | Power Supply | 12 VDC, 1 A | | Power Consumption | <6.5 W | | Operating Conditions | 14 to 122°F / -10 to 50°C
Less than 95% RH | | Storage Conditions | 14 to 122°F / -10 to 50°C
Less than 95% RH | | IP Rating | IP67 | | Casing Material | Metal and plastic | | Certifications | Safety: UL 60950
Electromagnetic Compatibility (EMC): FCC CFR 47 Part 15 Subpart B, 2AATL-8112MET | | Dimensions | 2.76 x 6.49" / 70 x 164.9 mm | | Weight | 0.84 lb / 0.38 kg | | | | Box Dimensions (LxWxH) | 8.25 x 4.3 x 3.9" | - 4 x EverFocus 12 VDC Slim Line Power Adapter
| | | Box Dimensions (LxWxH) | 3.7 x 3.0 x 1.15" | - WD 1TB Purple 5400 rpm SATA III 3.5" Internal Surveillance HDD Retail Kit
| | | Drive Capacity | 1.0 TB | | Cache Memory | 64 MB | | | | Interface | SATA III (6 Gb/s) | | Sequential Read Speed | 110 MB/s | | Sequential Write Speed | 110 MB/s | | | | Drive Type | HDD | | Form Factor | 3.5" | | Noise Level | 22.0 dB (Active)
20.0 dB (Idle) | | | | Spindle Speed (RPM) | 5400 RPM | | | | Load/Unload Cycles | 300,000 | | Non-Recoverable Read Errors per Bits Read | < 1 in 1014 | | | | Power Draw | 3.3 W (Active)
2.9 W (Idle)
0.7 W (Standby) | | | | Operating Shock | 65 G / 2.0 ms | | Storage Shock | 250 G / 2.0 ms | | Operating Temperature | 32 to 149°F / 0 to 65°C | | Storage Temperature | -40 to 158°F / -40 to 70°C | | | | Certifications | RoHS, as per Manufacturer | | Dimensions (W x H x D) | 1.0 x 4.0 x 5.8" / 26.1 x 101.6 x 147.0 mm | | Weight | 1 lb / 0.5 kg | | | | Box Dimensions (LxWxH) | 8.0 x 6.0 x 4.0" |
