Product description The Datavideo MCU-100S is a handheld camera controller that allows you to control up to 4 Sony video cameras from up to 3280 ft using the included AD-1 adapters. The interface between the controller and AD-1 adapters is a RS-422 differential line and you can also use CAT5e/6 cables for the same distance.
This controller lets you adjust your cameras all by yourself without having to leave your multi-view monitor. It also allows you to store and recall memory settings within 3 memory banks.
The iris knob on this controller is not a position knob but instead a rotary knob that increases or decreases the current setting. So you can have camera 1 selected, which is at iris position 1, then switch to camera 2. Camera 2 will be at whatever setting it is at currently, and the knob will be used to increase or decrease the setting. Then, you can switch to the next camera and do the same. In this way, you can tune each camera to have its own individual iris settings. - Compatible Cameras
-
- Sony EX3
- Sony PMW F5
- Sony PMW 300K1
- Sony PMW 350K
- Control Functions
-
- Record and Playback
- Camera User Memory
- OSD Menu Navigation
- Shutter speed and degree
- Iris adjustment
- AWB and ABB
- White Balance A, B, and Preset
- Camera Knee and Bar
- Camera Gain adjustment
- RGB / R & B gain and Master Pedestal Controls
UPC: 672255006580 In the Box Datavideo MCU-100S Handheld Camera Controller for Sony Cameras 4 x AD-1 Adapter for MCU-100/200 Controller duyczuxaczaftzvtcqys 12V Power Adapter Quick Start Guide Limited 1-Year Warranty Limited 2-Year Warranty with Product Registration within 30 Days of Purchase Table of Contents
|
Upload User Manual
Have you got an user manual for the Datavideo MCU-100S Handheld Camera Controller for Sony Cameras in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDatavideo MCU-100S Specs | Maximum Distance | 3280 ft (1000 m) | | Connections | CAM/BS (from Panasonic Camera to AD-1 Adapter)
RJ-45 (from AD-1 Adapter to MCU-100S)
CVBS (from AD-1 Adapter to Preview Screen)
Although the MCU-100 uses an RJ-45 connector, it uses the RS-422 protocol to control the camera. Therefore, wired or wireless Ethernet cannot be used on the MCU-100. | | Dimensions | 3.8 x 8.2 x 2.1" (9.7 x 20.8 x 5.3 cm) | | Weight | 0.6 lb (272 g) | | | | Package Weight | 3.0 lb | | Box Dimensions (LxWxH) | 11.5 x 10.0 x 4.2" |
