DECIMATOR DMON-4S 4 x SD HD

Search your instruction manual in PDF to download

User Manual for DECIMATOR DMON-4S 4 x SD HD 3G-SDI to HDMI Converter with Quad Multi-Viewer Function

Click to enlarge the picture
DECIMATOR DMON-4S 4 x SD HD 3G-SDI to HDMI Converter with Quad Multi-Viewer Function Contents of the user manual for the DECIMATOR DMON-4S 4 x SD HD
  • Product category: Signal Converters DECIMATOR
  • Brand: DECIMATOR
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for DECIMATOR Signal Converters

DECIMATOR DMON-4S 4 x SD HD 3G-SDI to HDMI Converter with Quad Multi-Viewer Function DECIMATOR DMON-4S 4 x SD HD 3G-SDI to HDMI Converter with Quad Multi-Viewer Function DECIMATOR DMON-4S 4 x SD HD 3G-SDI to HDMI Converter with Quad Multi-Viewer Function DECIMATOR DMON-4S 4 x SD HD 3G-SDI to HDMI Converter with Quad Multi-Viewer Function
User manual for the DECIMATOR DMON-4S 4 x SD HD contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any DECIMATOR product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official DECIMATOR user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a DECIMATOR product will considerably shorten its lifespan!



Product description

Packing four independent SDI to HDMI converters into a small field friendly package the DECIMATOR DMON-4S 4 x SD/HD/3G-SDI to HDMI Converter with Quad Multi-Viewer Function allows you to convert four separate SDI streams to either four independent mini HDMI outputs, or combine the SDI inputs into a Quad-Split HDMI output. The unit supports SD/HD/3G-SDI formats featuring automatic signal detection, and the built-in LCD info screen and button controls allow you to set your output options without resorting to DIP switch settings or connecting the unit to a computer.

You can set the converter to convert four SDI inputs to four HDMI outputs, combine the four SDI inputs into a Quad-Split HDMI output on one or all four of the HDMI outputs. You can also set the unit to convert two SDI inputs to HDMI, and use the other two SDI inputs as loop through outputs. When in Quad-Split mode, you can assign the audio from any input to be used as the audio for every output. The threaded locking power socket helps prevent accidental power loss from kickouts.
    Firmware Updates
  • Firmware Release 2.0.8 Adds customizable 8-Channel Audio Metering for each window in Multi-Viewer Mode

    Firmware Release 2.0.6 adds 3G-SDI Level B support for 1080p60/59.94/50 for this model, as well as horizontal and vertical image flipping per window, custom UMDs, and custom layout features that move it from a fixed window quad-split to a customizable 1-to-4 channel multi-viewer.

Features

  • Four independent mini HDMI outputs can each output any of the four (3G/HD/SD)-SDI inputs or a Quad-Split of all them. Four independent SDI to HDMI converters provide you with the following selections:
    • Four SDI inputs to four HDMI outputs
    • Four SDI inputs to Quad-Split HDMI outputs
    • Two SDI inputs to two mini HDMI outputs, and two SDI loop through outputs
    • A single SDI or Quad-Split to four HDMI outputs
  • In Quad-Split mode you can select the audio from any input to play as the audio for any of the outputs.
  • The LCD and button control system incorporated in the unit allows you access to all of the unit's features without using dip switches or having to carry around a computer to change a simple setting.
In the Box DECIMATOR DMON-4S 4 x SD/HD/3G-SDI to HDMI Converter with Quad Multi-Viewer Function
  • Universal Power Supply
  • HDMI Cable
  • USB Cable
  • Limited 3-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the DECIMATOR DMON-4S 4 x SD HD 3G-SDI to HDMI Converter with Quad Multi-Viewer Function in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    DECIMATOR DD-4S Specs

    Inputs SD/HD.3G-SDI: 4 x BNC
    Outputs HDMI: 4 x Type C
    SDI Formats Supported 3G: SMPTE 424M 2.97 and 2.967 Gb/s
    1080p: 60/59.94/50 Hz

    HD: SMPTE 292M/274M/296M 1.485 and 1.435 Gb/s
    1080i: 60/59.94/50 Hz
    1080p/psf: 30/29.97/25/24/23.98 Hz
    720p: 60/59.94/50/30/29.97/25/24/23.98 Hz

    SD: SMPTE 259M 270 Mb/s
    525i: 59.94
    625i: 50
    Control Buttons
    • Status for all four inputs
    • HDMI output type and source selection from SDI inputs 1 to 4
    • Quad-Split output format selection
    • Quad-Split output aspect and type of 16:9 or 4:3 at either 90 or 100% of screen size
    • Quad-split individual aspect format for each input of Same as output, Letter-box or Pillar-box
    • Quad-split Border Enable
    • Quad-split mode reference of either Free-run or inputs 1 to 4
    Power 5 to 32 VDC
    Pin Positive
    Dimensions 3.1 x 4.8 x 1.2" / 79.5 x 123 x 29.5 mm
    Package Weight 1.75 lb
    Box Dimensions (LxWxH) 10.2 x 6.3 x 2.5"

    Rating

    96% users recommend this product to others. And what about you?
    Rating: 4.8 of 5

    This product has already been rated by 87 owners. Add your rating and experience with the product.
