User Manual for Dell S2716DG 27" Widescreen LED Backlit LCD TN Gaming Monitor Click to enlarge the picture
Contents of the user manual for the Dell S2716DG 27" Widescreen LED Backlit
- Product category: Computer Monitors Dell
- Brand: Dell
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Dell Computer Monitors
 |
User manual for the Dell S2716DG 27" Widescreen LED Backlit contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Dell product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Dell user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Dell product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More wyweyybyttzbbtcdqcwdessvvzdzcxdct By combining a 1ms response time with NVIDIA G-Sync technology, the S2716DG 27" Widescreen LED Backlit LCD TN Gaming Monitor from Dell nearly eliminates all lag and ghosting when playing intense, fast moving games. With NVIDIA G-Sync technology built-in to this Dell monitor the display refresh rate of 144 Hz can be synced to the GPU in a GeForce GTX-powered computer to improve the overall viewing experience. In addition to the enhanced responsiveness of the display, you can take advantage of a QHD 2560 x 1440 resolution, a 1,000:1 contrast ratio, and a brightness rating of 350 cd/m². Setup and configuration is simple with HDMI 1.4 and DisplayPort 1.2 connectors, as well as four USB 3.0 ports to connect peripherals such as mice, keyboards, and other USB compatible devices directly to the monitor. Once setup, the S2716DG can be maneuvered into place by tilting, pivoting, and adjusting the height of the display to maximize viewing comfort. - Clear Motion
- Experience sharp and undistorted moving images with NVIDIA G-Sync and a fast refresh rate at 144 Hz for sharp, jitter-free graphics that drastically reduce motion blur.
- Reduced Lag
- Enjoy swift and responsive gameplay with minimum input lag at a rapid 1 ms panel response time.
- QHD Resolution
- Enjoy edge-to-edge gameplay with the Dell 27 Gaming Monitor, equipped with a crisp QHD resolution of 2560 x 1440 supporting up to 3.68 million pixels giving you close to two times more details on screen than Full HD.
- Improved Viewing Comfort
- With tilt, pivot, swivel, and height adjustable features, you can find your ideal viewing position, and game for long hours comfortably.
- Versatile Connectivity
- Connect easily to secondary devices and peripherals like your headphones, mouse, and keyboard with a wide range of ports, including an HDMI 1.4, DisplayPort 1.2, and 4 USB 3.0 downstream ports.
UPC: 884116197560 In the Box Dell S2716DG 27" Widescreen LED Backlit LCD TN Gaming Monitor Monitor Stand Power Cable DisplayPort Cable USB 3.0 Upstream Cable Limited 3-Year Warranty User Manual PDF 1.8mbwyweyybyttzbbtcdqcwdessvvzdzcxdct More info from Dell Table of Contents
|
Upload User Manual
Have you got an user manual for the Dell S2716DG 27" Widescreen LED Backlit LCD TN Gaming Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDell S2716DG Specs | | | Size | 27" | | Panel Type | TN LCD | | Touchscreen | No | | Resolution | 2560 x 1440 | | Aspect Ratio | 16:9 | | Finish | Matte | | Hardness Rating | 3H | | Maximum Brightness | 350 cd/m2 | | Contrast Ratio | 1000:1 | | Refresh Rate | 144 Hz | | Adaptive Sync Technology | None | | Bit Depth / Color Support | 8-Bit (16.7 Million Colors) | | Color Gamut | 82% CIE1976
72% CIE1931 | | Response Time | 1 ms | | Viewing Angle | Horizontal: 170°
Vertical: 160° | | Dot Pitch | 0.2331 x 0.2331 mm | | | | Connectivity | 1 x 3.5 mm Input/Output
1 x 3.5 mm Output
4 x USB Type-A (USB 3.1 Gen 1) Output
1 x DisplayPort 1.2 Input
1 x HDMI 1.4 | | | | Power Consumption | 32.6 W (Eco)
0.5 W (Standby)
90 W (Maximum)
47 W (Typical) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 1.5 A | | | | Operating Temperature | 32 to 104°F / 0 to 40°C | | Storage Temperature | -4 to 140°F / -20 to 60°C | | Operating Humidity | 10 to 80% | | Storage Humidity | 5 to 90% | | Operating Altitude | 0 to 16,404' / 0 to 5000 m | | Storage Altitude | 0 to 40,000' / 0 to 12,192 m | | Certifications | ENERGY STAR, EPEAT Silver, RoHS, TCO Certified, as per Manufacturer | | | | Height Adjustment | 5.1" / 13 cm | | Mounting-Hole Pattern | 100 x 100 mm | | Lock Slot | Yes | | Dimensions (W x H x D) | 24.1 x 16.4 x 7.9" / 61.2 x 41.6 x 20.0 mm (With Stand)
24.1 x 14.3 x 2.2" / 61.3 x 36.3 x 5.6 mm (Without Stand) | | Weight | 9.7 lb / 4.4 kg (Without Stand) | | | | Package Weight | 22.2 lb | | Box Dimensions (LxWxH) | 28.0 x 17.5 x 8.0" |
