User Manual for Dell U2412M 24" UltraSharp LED Monitor Click to enlarge the picture
Contents of the user manual for the Dell U2412M 24" UltraSharp LED Monitor
- Product category: Computer Monitors Dell
- Brand: Dell
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Dell Computer Monitors
 |
User manual for the Dell U2412M 24" UltraSharp LED Monitor contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Dell product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Dell user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Dell product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More The Dell U2412M 24" UltraSharp LED Monitor has a number of good things going for it, from multiple inputs (DVI-D with HDCP, DisplayPort, and VGA) to a high 1920 x 1200 resolution and ultra fast 8 ms response time, the U2412M is a fast, accurate, and detailed screen. In addition to the aforementioned interfaces the monitor also sports 4 USB 2.0 ports for connection of numerous devices. Other viewing quality features include a 1000:1 contrast ratio, 300 cd/m² brightness, 16.7 million supported colors, and a 178° by 178° viewing angle. The U2412M also allows you to tailor it to your needs with height, tilt, swivel, and rotate adjustability. You can also adjust the colors and text for ideal viewing and reading. The screen additionally boasts an ENERGY STAR 5.1 rating, ensuring future energy savings. It also features VESA wall mounting capabilities and security slots to prevent theft. - It's Okay to Stare
- Whether for work or for play, the Dell UltraSharp U2412M can deliver an unmatched viewing experience Clearly outstanding: Watch your graphics come to life on a vast 24" LED-backlit screen featuring a crystal-clear 1920 x 1200 resolution on a 16:10 widescreen aspect ratio so you can't lose screen area just because your customized applications support a different resolution Contrasting view: Get ready for blur-free viewing with a 2 million:1 high dynamic contrast ratio and an 8 ms with overdrive gray-to-gray response time that helps ensure crisp, sharp, and ghost-free images Colorful character: Enjoy an amazing range of rich, dramatic, and accurate colors, thanks to IPS technology designed to give you color consistency across a broad viewing angle and a wide color gamut at 82% Premium panel guarantee: 100% replacement of Dell UltraSharp series monitors sold if any bright pixel is found, valid within the warranty period
- Your Monitor, Your Style
- The ultimate in flexibility and customizability, the U2412M monitor can be adjusted to suit your workspace, tailored to suit your viewing preferences, and with its wide viewing angle, it can be viewed from almost any position Height adjustability: Raise or lower the U2415M to suit your workspace and your personal style with 4.5" of height adjustability Versatile connectivity: Connect a keyboard, mouse, and other peripherals via USB ports, DisplayPort, and DVI ports that can deliver outstanding image quality when viewing HD content Maximum flexibility: Position your monitor just the way you like with comfort-enabling features like tilt, swivel, and rotate. IPS (in-plane switching) technology helps ensure a great view from almost any angle Supreme adaptability: Make colors cooler or warmer to suit your preference with the color temperature slider, while "Text mode" automatically adjusts screen brightness to 150 cd/m², ideal for reading text
- Designed with the Environment in Mind
- Your workspace isn't the only environment that can benefit from the U2412M Environmental compliance: The U2412M meets ENERGY STAR 5.1, EPEAT Gold and TCO Certified Displays 5 standards, and is also CECP and CEL compliant Power management: PowerNap allows you to control monitor brightness level or to put it in sleep mode to conserve power, and Dynamic dimming software automatically dims onscreen brightness when displayed images are overly bright or white. You can even activate the energy usage bar to see the U2412M's energy consumption Responsible construction: The U2412M is made of environmentally responsible materials, consisting of an arsenic-free and mercury-free LED panel and halogen-free laminates in its circuit boards, designed to consume less energy than a conventional monitor
UPC: 884116064244 In the Box Dell U2412M 24" UltraSharp LED Monitor Stand Power Cable DVI Cable USB Cable VGA Cable Safety Information Quick Setup Guide Drivers and Documentation Media Limited 3-Year Warranty More from Manufacturer More info from Dell Table of Contents
|
Upload User Manual
Have you got an user manual for the Dell U2412M 24" UltraSharp LED Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDell U2412M Specs | | | Size | 24" | | Screen Area | 20.3 x 12.7" / 51.8 x 32.4 cm | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 1920 x 1200 | | Aspect Ratio | 16:10 | | Finish | Matte | | Hardness Rating | 3H | | Maximum Brightness | 300 cd/m2 | | Contrast Ratio | 1000:1 | | Dynamic Contrast Ratio | 2,000,000:1 | | Refresh Rate | 60 Hz | | Adaptive Sync Technology | None | | Bit Depth / Color Support | 8-Bit (16.7 Million Colors) | | Response Time | 8 ms (GtG) | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | Dot Pitch | 0.27 x 0.27 mm | | | | Connectivity | 1 x USB Type-B 2.0 Input
4 x USB Type-A 2.0 Output
1 x DVI-D
1 x DisplayPort Input
1 x VGA | | | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 1.5 A | | | | Operating Temperature | 32 to 104°F / 0 to 40°C | | Storage Temperature | -4 to 140°F / -20 to 60°C | | Operating Humidity | 10 to 80% | | Storage Humidity | 5 to 90% | | Operating Altitude | 0 to 10,000' / 0 to 3048 m | | Storage Altitude | 35,000' / 10,668 m | | Certifications | ENERGY STAR, EPEAT GOLD, TCO Certified, as per Manufacturer | | | | Mounting-Hole Pattern | 100 x 100 mm | | Lock Slot | Yes | | Dimensions (W x H x D) | 14.2 x 21.9 x 2.6" / 36.2 x 55.6 x 6.5 mm (Without Stand)
20.2 x 21.9 x 7.1" / 51.4 x 55.6 x 18.0 mm (With Stand) | | Weight | 8.7 lb / 3.9 kg (Without Stand) | | | | Package Weight | 18.5 lb | | Box Dimensions (LxWxH) | 25.7 x 16.0 x 9.5" |
Rating94% users recommend this product to others. And what about you?
This product has already been rated by 20 owners. Add your rating and experience with the product.
