User Manual for Denecke AC-2RM Rackmount Counter Click to enlarge the picture
Contents of the user manual for the Denecke AC-2RM Rackmount Counter
- Product category: Time Code Generators & Readers Denecke
- Brand: Denecke
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Denecke Time Code Generators & Readers
|
User manual for the Denecke AC-2RM Rackmount Counter contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Denecke product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Denecke user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Denecke product will considerably shorten its lifespan!
|
Product description The AC-2RM Rackmount Counter from Denecke is a studio footage counter designed for placement in a standard 19" equipment rack. This unit directly drives the TC-Maxi studio time-code reader and displays footage, speed, runtime, and time code.
The unit can be controlled with input from the internal counter or an external time-code source. It includes automatic zero re-set from the projector changeover or total runtime footage. Remote operation includes reset, hold, A/B projector, input, time-code/counter, time, code/userbits, and auto reset.
The unit generates a stop-pulse at zero and frame blanking can be used with hour digits and frames above 20fps. Its memory stores the last count when the unit is turned off. It will also show negative counts. - TC-Maxi Counter
- This unit directly drives the TC-Maxi studio time code reader and displays footage, speed, runtime, and time code.
- Rackmount
- It is designed for placement in a 19" equipment rack.
In the Box Denecke AC-2RM Rackmount Counter Footage/Frame Counter One-Year Warranty Against Defects in Material & Workmanship Table of Contents
|
Upload User Manual
Have you got an user manual for the Denecke AC-2RM Rackmount Counter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDenecke EC-2RM Specs | Input | A and B biphase 5V logic
Time code in remote function control | | Output | Footage counter time code
TC-Maxi interface
Optically isolated zero stop switch 24V @100mA
Time Code out differential 1V running at 30fps
5Vencoder power | | Frame Rates | 0.5, 1, 2, 4, 5, 8, 10, 20, 25, 32, 40, 50, 80, 100, 160 pulses per frame | | Power | 12 to 18V @ 2A | | Dimensions (HxWxD) | 1.75 x 19" (HxW)
Depth not specified by manufacturer | | Weight | 5 lbs | | | | Package Weight | 4.0 lb | | Box Dimensions (LxWxH) | 14.0 x 12.0 x 6.0" |
