User Manual for Denon HEOS Amp Wireless Amplifier Click to enlarge the picture
Contents of the user manual for the Denon HEOS Amp Wireless Amplifier
- Product category: Amplifiers Denon
- Brand: Denon
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Denon Amplifiers
 |
User manual for the Denon HEOS Amp Wireless Amplifier contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Denon product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Denon user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Denon product will considerably shorten its lifespan!
|
Product description Add multi-room audio functionality to your speakers with the Denon HEOS Amp Series 2 Wireless Amplifier. This amplifier connects to a pair of stereo speakers and a subwoofer, delivering up to 70W per channel thanks to its Class-D amp and is capable of driving speakers rated down to 4 Ohms. It connects to your home network via Ethernet and 802.11ac Wi-Fi, mobile devices via Bluetooth and a 3.5mm stereo jack, digital sources via optical, and legacy devices via RCA. A USB port lets you connect a thumb drive or charge your mobile device. The Amp is controlled via a free app for Android and iOS or via the volume and mute controls on the side panel. The app also lets you play tracks from your smartphone or streaming sources with high-resolution audio support. The HEOS Amp can also be voice-controlled via your Amazon Alexa, Google Assistant, Siri, or Josh.ai ecosystem. - Alexa Voice Command
- Ask Alexa to play music from Pandora, Spotify, Amazon Music, and much more. Switch between inputs, turn volume up or down, pause, mute and play the next song, all with your voice. To start streaming with Alexa voice commands, the HEOS Home Entertainment skill must be added and activated via the Alexa app.
- Google Assistant Voice Control
- Ask your Google Assistant-enabled device to control content across your listening environment. Start music in the HEOS app, then ask your Google Assistant to control volume, playback, and more.
- AirPlay 2 with Siri Compatibility
- Stream audio from your favorite music services like Apple Music and Spotify, or watch videos from services like YouTube and Netflix from any compatible iPhone, iPad, Mac, or Apple TV device, and hear the audio synced to your sources. AirPlay 2 also supports multi-room audio, enabling you to wirelessly stream content to multiple AirPlay 2-compatible devices simultaneously with smooth playback. AirPlay 2 provides control and grouping of compatible devices within the Apple Music or Home apps. Use AirPlay 2 in-app or with your voice via Siri.
- Josh.ai Smart Home Voice Automation
- Josh.ai is designed to offer flexible voice control for nearly any aspect of your day-to-day experience and entertainment environment. Use voice commands to control your thermostat, lights, appliances, speakers, receiver, and more. Josh.ai is installed by custom integrators and accessed through an app on your compatible iOS or Android phone or tablet.
UPC: 883795003919 In the Box Denon HEOS Amp Wireless Amplifier (Series 2) Power Cable 3.5mm Setup Cable Ethernet Cable Limited 2-Year Warranty More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the Denon HEOS Amp Wireless Amplifier in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDenon HEOSAMPHS2SR Specs | | | Number of Channels | 2.1 | | Power Rating | 70 W + 70 W (8 Ohms, 20 Hz to 20 kHz, 0.05% THD)
100 W + 100 W (6 Ohms, 1 kHz, 0.7% THD | | Frequency Response | 10 Hz to 40 kHz, +1/-3 dB | | Signal to Noise Ratio | Analog In: 86 dB (10 W, 6 Ohms, IHF-A) | | Total Harmonic Distortion (THD) + N | Analog In: 0.5% (1 kHz) | | Impedance | 4 to 16 Ohms | | Input Sensitivity and Impedance | 150 mV / 47 kOhms | | | | Input | 1 x RJ-45 Ethernet
1 x Digital optical
1 x USB (5 V, 1 A)
2 x RCA (stereo pair)
1 x 3.5 mm
1 x AC power | | Output | 4 x Speaker terminal (2 x stereo pairs)
1 x Subwoofer | | | | Wi-Fi | 802.11 a/b/g/n/ac | | Frequency Range | 2.4 GHz, 5 GHz | | | | Supported Audio Formats and Codecs | PCM (WAV): 32/44.1/48/88.2/96/176.4/192 kHz, 16/24-bit
MPEG-1 Audio Layer 3/CBR/VBR (MP3): 32/44.1/48 kHz, 16-bit, 32 to 320 kbps
AAC-LC (M4A, AAC): 32/44.1/48 kHz, 16-bit, 48 to 320 kbps
WMA9/CBR (WMA): 32/44.1/48 kHz, 16-bit, CBR: 48 to 320 kbps
FLAC: 44.1/48/88.2/96/176.4/192 kHz, 16/24-bit
ALAC (M4A): 44.1/48/88.2/96/176.4/192 kHz, 16/24-bit | | Buttons and Indicators | Volume up and down buttons
Mute button
Network connect button
Bluetooth connect button
Multi-color LED status indicator | | Power Supply | 120 VAC, 60 Hz | | Power Consumption | Operation: 60 W
Quick Start Mode: 4.5 W
Deep Standby Mode: 0.3 W | | Operating Temperature | 41 to 95°F (5 to 35°C) | | Dimensions | 8.7 x 3.7 x 8.4" (22.1 x 9.3 x 21.4 cm) | | Weight | 6.2 lb (2.8 kg) | | | | Package Weight | 11.0 lb | | Box Dimensions (LxWxH) | 15.0 x 14.0 x 8.0" |
