User Manual for Denon HEOS AVR 5.1-Channel Network A V Receiver Click to enlarge the picture
Contents of the user manual for the Denon HEOS AVR 5.1-Channel Network A
- Product category: Receivers Denon
- Brand: Denon
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Denon Receivers
 |
User manual for the Denon HEOS AVR 5.1-Channel Network A contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Denon product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Denon user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Denon product will considerably shorten its lifespan!
|
Product description Enjoy wireless surround sound and wireless multi-room support with the Denon HEOS AVR 5.1-Channel Network A/V Receiver. You can connect a traditional 5.1-channel speaker system to its speaker binding posts and RCA subwoofer output, or use your HEOS wireless speakers as your rear surround speakers and the HEOS wireless subwoofer, plus pair it with other HEOS speakers throughout the house. It delivers up to 50W of power per wired channel at 8 Ohms and features compatibility with various Dolby and DTS standards to create an immersive audio experience.
Onboard Wi-Fi and Ethernet connectivity allow the HEOS AVR to access a variety of Internet-based music sources, as well as provide control via your smartphone with the free HEOS app. Additionally, the HEOS AVR can be voice-controlled via your Amazon Alexa, Google Assistant, Siri, or Josh.ai ecosystem. You can also stream music from your compatible device via Bluetooth. The receiver's four HDMI inputs and one HDMI output support 4K and 3D, plus the output is ARC-compatible for the reproduction of display-based audio, such as built-in apps. Note: Access to certain Internet-based content may require a subscription to a service. Not all services are available in all areas. - Alexa Voice Command
- Ask Alexa to play music from Pandora, Spotify, Amazon Music, and much more. Switch between inputs, turn volume up or down, pause, mute and play the next song, all with your voice. To start streaming with Alexa voice commands, the HEOS Home Entertainment skill must be added and activated via the Alexa app.
- Google Assistant Voice Control
- Ask your Google Assistant-enabled device to control content across your listening environment. Start music in the HEOS app, then ask your Google Assistant to control volume, playback, and more.
- AirPlay 2 with Siri Compatibility
- Stream audio from your favorite music services like Apple Music and Spotify, or watch videos from services like YouTube and Netflix from any compatible iPhone, iPad, Mac, or Apple TV device, and hear the audio synced to your sources. AirPlay 2 also supports multi-room audio, enabling you to wirelessly stream content to multiple AirPlay 2-compatible devices simultaneously with smooth playback. AirPlay 2 provides control and grouping of compatible devices within the Apple Music or Home apps. Use AirPlay 2 in-app or with your voice via Siri.
- Josh.ai Smart Home Voice Automation
- Josh.ai is designed to offer flexible voice control for nearly any aspect of your day-to-day experience and entertainment environment. Use voice commands to control your thermostat, lights, appliances, speakers, receiver, and more. Josh.ai is installed by custom integrators and accessed through an app on your compatible iOS or Android phone or tablet.
- Surround Yourself with Sound, Not Wires
- The HEOS AVR is wireless surround sound capable to drive your favorite wired speakers and any HEOS wireless speaker as surround channels.
- Multiple Setup Options
- Your HEOS AVR can be wirelessly connected to any single or set of HEOS speakers in a 2-, 2.1-, 3.1-, or 5.1-channel configuration.
- Connect with the HEOS App
- Connect the HEOS AVR and your display with an HDMI cable, get the HEOS App, and follow the instructions. Within minutes, you'll be ready to listen. Control all your sound via the app, or command the HEOS AVR with the remote of your display.
- Mix and Match Wired and Wireless Speakers
- Amp up your movie sound with a dedicated 3.1-channel setting without getting tangled wires. Add any pair of wireless HEOS speakers to expand your setup.
- Take Control
- With the remote control of the HEOS AVR, you have the main functions at hand. Additionally, it offers instant access to six audio presets, so you can choose between optimized settings for different music or movie scenarios.
- Get the HEOS Experience
- Connect any HEOS device you like and fill your home with sound, not wires. Stream all your music to any room, or the same music to all rooms, using your home network. Share tunes from your smartphone via Bluetooth. Have it all at your fingertips with the HEOS app.
- Encounter Ultra HD
- Four HDMI 2.0a/HDCP 2.2 inputs help ensure that you can enjoy your movies in Ultra HD, with compatible media and other equipment. Dolby TrueHD, DTS-HD Master Audio provide for an immersive audio experience to accompany your UHD video.
- App & Streaming Services
- Cloud music, streaming music, and your music library are all supported by the free HEOS app.
- Designed for Simple Setup
- Place your speakers, and you will be listening to music in minutes.
- Additional Features
-
- Combines up to 5.1-channel surround sound with the ease-of-use of a soundbar
- Five 100W class D amplifiers are capable to drive your favorite speakers
- Add wireless surround channels using any pair of HEOS speakers
- Industrial design with aluminum chassis
- 4K Ultra HD compatibility with four HDMI inputs
- Bluetooth streaming
- Six Quick Selects for favorite functions and radio stations
- Built-in HEOS network technology for access to online streaming services, plus a multi-room experience with other HEOS products
- Control basic functions of the HEOS AVR through your display
UPC: 883795003995 In the Box Denon HEOS AVR 5.1-Channel Network A/V Receiver Remote Control CR2025 Battery 1/8" Audio Setup Cable HDMI Cable Optical TOSLINK Cable Ethernet Cable Limited 2-Year Warranty More from Manufacturer ywrwqyfvzyaaxcysvesszzuxxq Table of Contents
|
Upload User Manual
Have you got an user manual for the Denon HEOS AVR 5.1-Channel Network A V Receiver in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDenon HEOSAVR Specs | | | Channels | 5.1 | | RMS Power Output per Channel | 50 W @ 8 Ohms, 20 Hz to 20 kHz, 0.05% THD, 2 channels driven
65 W @ 6 Ohms, 20 Hz to 20 kHz, 0.1% THD, 2 channels driven
100 W @ 4 Ohms, 20 Hz to 20 kHz, 0.1% THD, 2 channels driven | | Discrete Amplification | Yes, 5 | | Sound Modes | DTS-HD Master Audio
Dolby TrueHD
Dolby ProLogic II
Multi-channel stereo | | | | Wi-Fi | Dual-band 2.4 / 5 GHz 802.11a/b/g/n/ac | | Inputs | 4 x HDMI
1 x Optical TOSLINK
1 x Digital coaxial
1 x USB
1 x Stereo RCA
1 x 1/8" (3.5 mm) AUX in | | Outputs | 1 x HDMI
1 x Subwoofer pre-out | | Other Connectors | 1 x Ethernet LAN
1 x IR in | | Speaker Connectors | 5 x Binding post pairs | | HDCP Support | HDCP 2.2 | | HDMI Pass-Through | 3D, 4K, CEC | | Bluetooth | Yes | | Media Streaming Support | Via USB/Network: DSD (2.4, 5.6 MHz), FLAC, WAV, ALAC (192 / 24), MP3, WMA, AAC | | | | Chassis Material | Aluminum | | Power Requirements | 120 VAC, 50/60 Hz | | Power Consumption (Active) | 110 W | | Power Consumption (Standby) | Typical: 0.3 W
CEC / Network Control Standby: 4.5 W | | Dimensions (W x H x D) | 17.13 x 3.63 x 11" (43.5 x 9.21 x 27.94 cm) | | Weight | 13.23 lb (6 kg) | | | | Package Weight | 18.0 lb | | Box Dimensions (LxWxH) | 21.5 x 14.8 x 10.0" |
Rating60% users recommend this product to others. And what about you?
This product has already been rated by 19 owners. Add your rating and experience with the product.
