User Manual for Digital Arts metaSETZ TLC-8LS Tally Controller for Livestream Studio Click to enlarge the picture
Contents of the user manual for the Digital Arts metaSETZ TLC-8LS Tally Controller
- Product category: Switcher Accessories Digital Arts
- Brand: Digital Arts
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Digital Arts Switcher Accessories
|
User manual for the Digital Arts metaSETZ TLC-8LS Tally Controller contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Digital Arts product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Digital Arts user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Digital Arts product will considerably shorten its lifespan!
|
Product description Configured for use specifically with the Livestream Studio and compatible with all metaSETZ tally lights and relay units, the metaSETZ TLC-8LS from Digital Arts provides eight assignable tally outputs, Program/Preview/Talent tally, two assignable dry-contact GPI outputs, and intercom/audio pass-through. It also allows you to assign any of the eight tally outputs to any of the switcher inputs in order to assign a tally to a network input or DDR.
The ability to run both tally and intercom over a single Cat5 cable highly sets the TLC-8LS apart from a simple adapter cable. You'll be able to connect your intercom base station into the XLR port on the rear of the TLC-8LS and then connect your belt packs to the multipurpose port on the tally lights.
The TLC-8LS works with the Livestream Studio software, so no additional software installation is required. - Supported Livestream Studio Version
-
- Compatible with all Livestream Studio v. 1.3 or higher models
UPC: 851957007044 In the Box Digital Arts metaSETZ TLC-8LS Tally Controller for Livestream Studio USB Power Cable Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Digital Arts metaSETZ TLC-8LS Tally Controller for Livestream Studio in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDigital Arts TLC-8LS Specs | Connections | 8 x Tally outputs
1 x 3-Pin XLR
1 x 15-pin D-Sub | | Supported Livestream Models | Compatible with all Livestream Studio v. 1.3 or higher models | | Power | USB port (USB cable included) | | | | Package Weight | 0.8 lb | | Box Dimensions (LxWxH) | 10.5 x 6.4 x 2.1" |
