Product description The DIGITAL FORECAST Bridge X Series HDMI & DVI to 3G-SDI Converter converts HDMI / DVI signals into SDI SMPTE-standard signals. It can support formats up to 1080p60 and features a selectable mux audio source between embedded HDMI and analog L/R. The converter also allows you to set the output in a specific format. In addition, it also comes with a built-in scaler. - HDMI or DVI to SDI converter
- Video scaler function inside high video processing engine
- Normal bypass mode or fixed scan converter mode for standard 1080i50/1080i59.94 broadcast formats
- Fixed format setting with USB serial (default: 1080i)
UPC: 704006295520 Table of Contents
|
Upload User Manual
Have you got an user manual for the DIGITAL FORECAST Bridge X Series HDMI & DVI to 3G-SDI Converter with Scaler in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDIGITAL FORECAST X_S2 Specs | Inputs | 1 x HDMI
1 x DVI
1 L/R stereo audio (stereo audio jack) | | Output | 2 x HD-SDI out (SD/HD/3G all standard formats) | | Formats | Supports HDMI v1.3
Supports DVI format
Supports multi-rate SDI formats
SMPTE 125M: NTSC (480i 59.94), PAL (576i 50)
SMPTE 296M: 720p (60/59.94/50)
SMPTE-274M, SMPTE-292M: 1080i (60/59.94/50) 1080p (30/29.97/25/24/23.98)
SMPTE-424M: 1080p (60/59.94/50) 3G | | Input Voltage | 12 VDC | | Power Consumption | 5.28 W
Maximum: 6 W | | Operating Temperature | -4 to 158°F (-20 to 70°C) | | Humidity | 0 to 95% RH, non-condensing | | Dimensions (W x H x D) | 4.13 x 3.7 x 0.98" (105 x 94 x 25 mm) | | Weight | 5.8 oz (165 g) | | | | Package Weight | 1.25 lb | | Box Dimensions (LxWxH) | 7.2 x 5.3 x 3.0" |
