Product description Centralize file storage, sharing, and backup in your existing Blackjack system with the 2 RU 40TB Blackjack 8-Bay NAS Server from Digital Watchdog. Seamlessly integrated into the Spectrum IPVMS system, this recording backup solution allows for continuous archiving, instant search, and optimized data management. The Blackjack 8-bay rackmount NAS is designed to be implemented into a Blackjack E-Rack system with a total throughput of up to 600 Mb/s, the equivalent of up to 128 2.1 MP single-sensor IP cameras. It combines up to eight hard drives into a mass storage solution that uses RAID 5 redundancy to protect your recorded video. - Add NAS station to a Blackjack E-Rack server with up to 128 cameras to quickly expand local storage and backup capacity at up to 600 Mb/s throughput
- RAID 5 for efficient storage with enhanced data security
- 40TB raw capacity; 30TB usable storage after RAID 5
- Enables adding and managing devices directly from the Spectrum IPVMS client software's user-friendly interface
- Seamless search via the Spectrum IPVMS client, including smart motion search, spyglass, and calendar search options
- Proprietary Linux embedded OS
In the Box Digital Watchdog Blackjack 8-Bay NAS Server (40TB, 2 RU) Network Cable Power Cable Rackmount Kit with Screws Front Door Lock Key HDD Screws Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Digital Watchdog Blackjack 8-Bay NAS Server in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDigital Watchdog DW-BJ8NAS40TR Specs | | | Total Raw Capacity | 40 TB | | Initial RAID Configuration | RAID 5 | | | | Number of Bays | 8 x 3.5" | | Connections | 2 x RJ45 (Gigabit Ethernet) | | Form Factor | Rackmount (2 RU) | | RAID Modes | RAID 5 | | Hot-Swap Support | Yes | | | | Supported Protocols | HTTP
SMTP
SNMP v1
SNMP v2
SNMP v3
iSCSI | | iSCSI Support | Yes | | Max Volume Number | 2 | | Max Cameras Supported | 128 | | | | Installed Operating System | Linux | | Supported File Systems | NTFS | | | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 1.5 to 4 A | | PSU Wattage | 1 x 250 W | | | | Operating Temperature | 41 to 104°F / 5 to 40°C | | Operating Humidity | 20 to 90% | | | | Status Monitoring | LCD Screen, LED Indicator | | Mounting Rails Included | Yes | | Dimensions | 17.4 x 3.5 x 18.0" / 44.2 x 8.9 x 45.7 cm | | Weight | 19.4 lb / 8.8 kg |
