User Manual for Digital Watchdog MEGApix DWC-MC421D 2.1MP 1080p Triple Codec IP Dome Camera Click to enlarge the picture
Contents of the user manual for the Digital Watchdog MEGApix DWC-MC421D 2.1MP 1080p
- Product category: Wired IP Cameras Digital Watchdog
- Brand: Digital Watchdog
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Digital Watchdog Wired IP Cameras
|
User manual for the Digital Watchdog MEGApix DWC-MC421D 2.1MP 1080p contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Digital Watchdog product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Digital Watchdog user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Digital Watchdog product will considerably shorten its lifespan!
|
Product description The MEGApix DWC-MC421D 2.1MP 1080p Triple Codec IP Dome Camera (NTSC) from Digital Watchdog provides 1080p resolution images at 30 frames per second. The camera’s advanced technologies like Electronic Day and Night, 3D-DNR, and WDR deliver quality images in any type of environment. Its Power over Ethernet capability simplifies installation by connecting both power and network through a single cable. ONVIF [Open Network Video Interface Forum] Profile S Conformant - Universal protocol that allows IP cameras to communicate with other manufacturers recorders
- Conformant with ONVIF protocol increases flexibility and reduces total cost
Resolution - True HD 1080p (1920×1080), 2.1 MP streaming and recording resolution
Power over Ethernet (PoE) - Enables the camera to receive power via the same network cables it uses to transmit data and video
- Simplifies the installation process, requiring only a single cable to power up, configure, and control the camera
Codecs - Triple codec (H.264, MJPEG, MPEG4) with simultaneous dual-stream
Lens - 3.5 to 16mm auto-focus zoom lens controlled remotely via camera's web-based UI
- 8x digital zoom and 4.5x optical zoom
3D Digital Noise Reduction (DNR) - Provides clearer images by using unique algorithms designed to reduce video noise
- Cleans electronic noise signals that reduce the clarity of the image and effect motion detection settings with various recording technology
Programmable Privacy Zones - Privacy masking is used to protect personal privacy by concealing parts of the image from view with a masked area, for example, masking windows of houses
- Up to 30 privacy zones can be programmed
2-Way Audio - Supports 2-way audio for communication running between the camera's web-based UI and the camera's location
BNC Output - Secondary BNC video output on board
- Allows proper mounting and set up on-the-spot
Wide Dynamic Range (WDR) - Enables to capture clear images in the same frame, even in both extreme bright and dark areas in the same field
Micro SD Card Support for Emergency Backup - Built-in micro SD card slot for emergency backup
- Camera starts recording locally when it detects network loss
- Micro SD/SDHC Class 10 card support up to 32GB
Other Features - IP66 certified (weatherproof)
- No fog or condensation under any weather conditions
- Event e-mail notifications
- C/CS mount lens compatible
UPC: 813379012761 In the Box Digital Watchdog MEGApix DWC-MC421D 2.1MP 1080p Triple Codec IP Dome Camera (NTSC) Mini-DIN Connector L-Wrench 9.0mm Adapter Ring 5.2 Port Terminal Block for Power Connection Limited 2-Year Warranty Guides & Manuals Table of Contents
|
Upload User Manual
Have you got an user manual for the Digital Watchdog MEGApix DWC-MC421D 2.1MP 1080p Triple Codec IP Dome Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Download User ManualThe user manual for the Digital Watchdog MEGApix DWC-MC421D 2.1MP 1080p Triple Codec IP Dome Camera can be downloaded in PDF format at the link stated below.
Technical parametersDigital Watchdog MC421D Specs | | | Image Sensor | 1/2.8" CMOS Sensor | | Minimum Illumination | F1.6 (30IRE): 0.5 lux [color] F1.6 (30IRE): 0.01 lux [B&W] | | Resolution | 2.1 MP, 1080p (1920 x 1080) | | Total Pixels (H x V) | 2,016 X 1,241 | | | | Digital Zoom | 8x Digital Zoom | | Lens Type | C/CS mount lens compatible (not included) | | Zoom | 8x digital zoom | | | | Frame Rate | Up to 30 frames per second at all resolutions on all streams | | LAN | 802.3 Compliance 10/100 LAN | | Number of Simultaneous Users | 4 (maximum) | | ONVIF Conformance | Profile S | | Protocols | TCP/IP, HTTP, DHCP, PPPoE, ICMP, ARP, RARP, RTSP, NTP, UDP, Multicast | | SD Card | Up to 24 hours to Micro SD Card (4 to 32 GB) for network loss emergency recording only (card not included) | | Streaming Capability | Dual-stream at different rates and resolutions | | Video Compression Format | H.264, MPEG4, MJPEG (Super fine to low) | | Video Management Software | DW Spectrum, Pivot CMS, DW's VMS | | Web Viewer | OS: Windows XP / Vista / 7, MAC OS
Browser: Internet Explorer, Chrome, Firefox, and Safari | | | | Brightness | 0 to 20 | | Shutter Modes | Auto/ Manual | | Digital Slow Shutter | Off/ 2x / 3x / 4x | | DNR | Off/ low / middle / high | | Gain Control | 0 to 20 (auto) | | BLC | Off / On | | Wide Dynamic Range | Off / On / Level 0 to 9 | | Day & Night | Auto/ day (color) / night (B&W) | | Lens | Manual / DC | | Chroma | 0t o 20 (Color Quality: Hue, & saturation settings) | | Sharpness | 0 to 10 | | Flip / Mirror | Off/ On | | Alarm Notification | Notifications via E-mail | | Privacy Zone | Off/ On (30 programmable zones) | | Motion Detection | Low/ Middle/ High | | Sensor | Input/ 1 output built-in | | Recording Schedule | Continuous/ motion/ sensor/ pre- & post- alarm | | Resolution | 1920 X 1080 (16:9) to 320 X 240 (4:3) | | IP | IPv4, IPv6 | | | | Operating Humidity | > 90% (Non-Condensing) | | Operating Temperature | 14 to 131°F (-10 to 55°C) | | Storage Temperature | -4 to 158°F (-20 to 70°C) | | Other Specifications | CE, FCC, RoHS | | | | Power Requirement | 12 VDC, PoE (IEEE802.3af Class 2) | | Power Consumption | 6.5 W, 550 mA | | | | Housing Material | Aluminum | | Housing Type | Color box | | Dimensions | 5.2 x 2.2" (13.1 x 5.5 cm) | | Weight | 8.8 oz (249.4 g) |
