Product description The 5.8 GHz Transmitter and Receiver Combo for Phantom 2 Quadcopter from DJI is intended to replace the original transmitter and receiver pair included with the Phantom 2 so that the aircraft can use 2.4 GHz accessories such as Lightbridge without the risk of radio interference. It is the same system that comes with the Phantom 2 Vision and Phantom 2 Vision+ models.
The transmitter is the hand-held radio controller while the receiver is the air-end component that installs inside the aircraft and interfaces with the flight control system. Installation of the receiver requires opening the Phantom 2's body shell, and will involve soldering. - Use 2.4 GHz accessories such as Lightbridge without interfering with the control signal
Table of Contents
|
Upload User Manual
Have you got an user manual for the DJI 5.8 GHz Transmitter and Receiver Combo for Phantom 2 Quadcopter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDJI CP.AL.000020 Specs | | | Operating Frequency | 5.728 to 5.8 GHz | | Transmit Power | 125 mW | | Communication Distance | Up to 2624.7 line-of-sight while meeting FCC requirements
Note: Operating at this power may not be approved in jurisdictions outside the U.S. | | Working Voltage | 80 mA at 6V | | Power Source | 8 x AA batteries | | Dimensions | Not specified by manufacturer | | Weight | Not specified by manufacturer | | | | Sensitivity | -93 dBm (1% PER) | | Power Source | Aircraft flight battery | | Dimensions | Not specified by manufacturer | | Weight | Not specified by manufacturer | | | | Package Weight | 1.9 lb | | Box Dimensions (LxWxH) | 10.5 x 8.7 x 4.1" | B&H Hands-on Learning Videos Hands-on Learning with the DJI 5.8 GHz Transmitter and Receiver Combo for Phantom 2 Quadcopter 00:03:54 - DJI Lightbridge - Phantom 2 Installation (5.8G Remote System) 3:54
