User Manual for DJI Osmo Pocket Gimbal with Expansion Kit and 32GB microSDHC Card Click to enlarge the picture
Contents of the user manual for the DJI Osmo Pocket Gimbal with Expansion
- Product category: Sports & Action Cameras DJI
- Brand: DJI
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for DJI Sports & Action Cameras
|
User manual for the DJI Osmo Pocket Gimbal with Expansion contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any DJI product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official DJI user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a DJI product will considerably shorten its lifespan!
|
Product description This DJI Osmo Pocket Gimbal with Expansion Kit put together by includes an Osmo Pocket gimbal, wireless module, controller wheel, accessory mount, and a 32GB microSD card.
The Osmo Pocket is a compact, handheld 3-axis gimbal stabilizer with a 1/2.3" sensor camera that records up to 4K60 video and takes 12MP stills. The wireless module allows you to connect your smartphone via Wi-Fi for gimbal and camera control. The mount can be used to add accessories to the gimbal, and the controller wheel provides fine pan and tilt control. A 32GB microSDHC card is also included. - DJI Osmo Pocket Gimbal
- DJI Osmo Pocket - Hands-On Review
- DJI - Meet Osmo Pocket
The DJI Osmo Pocket Gimbal is a lightweight gimbal stabilizer and 4K camera combination that is compact enough to carry wherever you go. Weighing just over four ounces and measuring only 4.8" high, this all-in-one unit features 3-axis stabilization to smooth out your movements. The Osmo Pocket incorporates a 1/2.3" sensor and a wide f/2.0, 80° angle-of-view lens to record up to 4K60 cinematic video and 12MP still photos on up to a 256GB microSD card. Use DJI's Mimo app and your iOS or Android smartphone to polish your footage with preset shooting patterns, camera motions, filters, and soundtracks. Connect the Osmo Pocket via the included USB Type-C or Lightning adapters to use your smartphone as a larger viewfinder with the Mimo app. Add the separately available Wireless Module for remote control and transmission. A Pro mode enables you to adjust the camera's ISO and exposure settings for maximum creativity. Unlike a similarly sized smartphone, the candy bar-sized Osmo Pocket offers intelligent functions like Active Track, FaceTrack, and Motionlapse to create compelling, creative effects. Choose between 180° and 3 x 3 panoramic shots to capture wide landscape vistas. The FPV mode provides a selfie perspective, and NightShot can be used to capture moonlit or low-light scenes. The Osmo Pocket's passive cooling system quietly dissipates heat, and a rechargeable battery enables the camera to record up to 140 minutes of 1080p video. Accessories like ND filters, a retractable extension stick, a waterproof case, and an accessory mount are available separately to round out your Osmo Pocket experience. Note: The optional Bluetooth Module is required for Bluetooth and Wi-Fi connectivity. Gimbal Features - Controllable range:
- Pan: -230 to +50°
- Tilt: -95 to +50°
- Roll: ±45°
Key Features -
- 3-axis stabilized 4K camera in an ultra-compact, lightweight form
- Capture up to 4K60 video and 12MP still photos
- Use with the Mimo app for Active Track, Face Track, Motionlapse, and other creative functions
- Links to your iOS or Android smartphone via the included Lightning and USB Type-C adapters
- Connects to use your smartphone as a larger display
- Employs a 1/2.3-inch sensor and an f/2.0 aperture for crisp, vivid 80° FOV images
- Rechargeable internal Li-Po battery lasts for up to 140 minutes
- Up to 100 Mb/s bit rate
- Records to up to a 256GB microSD card
Mimo App - iOS
Requires iOS 10.0 or later and is compatible with:- iPhone XS Max / XS / XR / X
- iPhone 8 Plus / 8
- iPhone 7 Plus / 7
- iPhone 6s Plus / 6s / 6 Plus / 6
- iPhone SE
- Android
Requires Android version 5.0 or later and is compatible with:- Google Pixel 2XL / Pixel
- Huawei P20 / P10 / Mate 10 Pro / Mate 10 / Mate 9 Pro / Mate 9
- Honor 10 / 9
- Mi Mix 2S / 8 / 6
- OnePlus 6T / 5T
- Vivo NEX
UPC: 190021324985 - DJI Osmo Pocket Expansion Kit
- DJI Osmo Pocket - Hands-On Review
- DJI - Meet Osmo Pocket
The DJI Osmo Pocket Expansion Kit provides a few add-on accessories that will let you do a lot more with your Osmo Pocket Gimbal.
The Controller Wheel attaches right below the LCD of the gimbal, facing the user, and provides a dial for precise pan and tilt control. The dial is comfortably accessible by thumb. A selector switch next to the dial allows you to choose whether the dial should control pan or tilt motion. There's also a button for changing shooting modes and another button for re-centering the gimbal.
The Wireless Module allows for remote control of the gimbal from your mobile device. It does this by providing a wireless connection between the two over Bluetooth and Wi-Fi while serving as a base. It can also be used just as a base. And it offers a USB-C connector for charging the gimbal.
The Accessory Mount provides a 2-prong mount for attaching 3-prong accessories on the front of the gimbal. It clasps on around the center of the gimbal.
A Samsung 32GB microSD card is also included in the kit. - Controller Wheel
- Provides a pan and tilt thumb dial, mode select button, and gimbal re-center button.
- Wireless Module
- Allows for remote control of the gimbal from your mobile device by providing a wireless connection between the two. It can also be used simply as a base, and it offers a USB-C connector for charging the gimbal.
- Accessory Mount
- Provides a 2-prong mount for attaching 3-prong accessories on the front of the gimbal. It clasps on around the center of the gimbal.
UPC: 190021329560 - SanDisk 64GB Extreme UHS-I microSDXC Memory Card with SD Adapter
- DJI Osmo Pocket - Hands-On Review
- DJI - Meet Osmo Pocket
Designed for microSD devices such as smartphones, interchangeable-lens cameras, drones, or GoPro action cameras that can capture Full HD, 3D, and 4K video, as well as raw and burst photography, the 64GB Extreme UHS-I microSDXC Memory Card from SanDisk has a capacity of 64GB, is compatible with the UHS-I bus, and features a speed class rating of V30, which guarantees minimum write speeds of 30 MB/s. If your device does not support the V30 standard, this card also supports the U3 standard, which also guarantees minimum write speeds of 30 MB/s. Read speeds are supported up to 160 MB/s and write speeds max out at 60 MB/s.
While this card has been designed for cameras that are UHS-I / V30 / U3 compatible, it may be used in devices that do not support UHS-I / V30 / U3. However, bear in mind that this card will then default to your device's speed class and bus rating, such as UHS-I and U1, which supports minimum write speeds of 10 MB/s, or Class 10, which also supports minimum write speeds of 10 MB/s.
Aside from support for UHS-I, V30, and U3, SanDisk also built this card with support for the Application Performance Class 2 (A2) spec, which includes optimizations to give Android users an improved mobile experience, delivering faster mobile app performance. The A2 spec allows the card to manage random read input-output access per second (IOPS) operations so it can quickly open apps and process accompanying tasks, such as audio, graphics, saved profiles, and in-app permissions.
As with most SanDisk media, this memory card is shockproof, X-ray proof, and waterproof, while also being able to withstand temperatures, allowing you to take this card with you into extreme environments. Should the card's data become compromised, you also benefit from the option to download RescuePRO Deluxe software, and SanDisk's Memory Zone app offers users a simple way to organize, browse, and back up files on their Android mobile device. Additionally, included is a microSD to SD adapter with a write protect switch, allowing this card to be used in SD-compatible devices. General Features - Read speeds up to 160 MB/s, write speeds up to 60 MB/s, and minimum write speeds of 30 MB/s
- Class 10, App Performance Class 2 (A2), Video Speed Class 30 (V30), and UHS Speed Class 3 (U3)
- Water / temperature / shock / x-ray proof
- SanDisk Memory Zone included
- RescuePRO Deluxe one-year file recovery software (download offer)
UPC: 619659169770 In the Box - Osmo Pocket Gimbal wbyqfbwwutdruxvzwwuzd
- USB-C Adapter
- Lightning (iOS) Smartphone Adapter
- Charging Cable
- Cover
- Limited 1-Year Warranty for Camera, Handle, Charger
- Limited 6-Month Warranty for Battery (< 400 Charge Cycles)
- Osmo Pocket Expansion Kit
Includes Free - SanDisk - 64GB Extreme UHS-I microSDXC Memory Card with SD Adapter
More info from DJI Table of Contents
|
Upload User Manual
Have you got an user manual for the DJI Osmo Pocket Gimbal with Expansion Kit and 32GB microSDHC Card in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - DJI Osmo Pocket Gimbal
| | | Sensor | 1-Chip 2/3" | | Effective Pixels | 12 MP (Photo) | | | | Maximum Aperture | f/2 | | Angle of View | Wide: 80° | | | | Recording Media | 1 x microSD (256 GB Maximum) | | Video Format | 3840 x 2160p at 24/25/30/48/50/60 fps (100 Mb/s MP4 via MPEG-4)
1920 x 1080p at 24/25/30/48/60 fps (100 Mb/s MP4 via MPEG-4) | | Still Image Resolution | JPEG: 12 Megapixel, 4000 x 3000 | | Sampling Frequency | AAC: 48.0 kHz | | | | Display Type | LCD | | Touchscreen | Yes | | Screen Size | 1.08" | | Status Display | Yes LED | | | | Shutter Speed | 8 - 1/8000 Second (Photo, Video) | | Photo ISO Range | 100 - 3200 (Manual) In Pro mode using the Mimo app. | | Video ISO Range | 100 - 3200 (Manual) In Pro mode using the Mimo app. | | Shooting Modes | Panorama
Self-Portrait
Time-Lapse Movie Face Track, Motionlapse, Object Track | | | | Image Stabilization | Digital 3-axis gimbal stabilization | | Scene Modes | Preset: Yes | | Built-In Mic | Yes | | Built-In Speaker | No | | Wi-Fi | Optional Requires optional module. | | Tripod Mount | None | | | | Inputs | 1 x USB 2.0 Type-C Charging | | Outputs | 1 x USB 2.0 Type-C Monitoring Via included USB Type-C or Lightning (iOS) adapter. | | Microphone Input | None | | | | Battery | Rechargeable Lithium-Ion Polymer Battery Pack, 7.7 VDC, 875 mAh
Battery Charge Time: 2 hours | | Charging Method | USB | | Charging Time | 1.25 Hours | | Dimensions (W x H x D) | 4.8 x 1.5 x 1.1" / 121.9 x 36.9 x 28.6 mm | | Weight | 4.09 oz / 116 g | | | | Box Dimensions (LxWxH) | 6.0 x 3.6 x 2.0" | - DJI Osmo Pocket Expansion Kit
| Dimensions | Controller Wheel:
1.8 x 1.2 x 0.9" / 4.5 x 3 x 2.3 cm
Wireless Module:
1.6 x 1" / 4 x 2.7 cm
Accessory Mount:
2 x 1.5 x 1.7" / 5 x 3.8 x 4.2 cm | | Weight | Controller Wheel:
0.34 oz / 9.7 g
Wireless Module:
0.44 oz / 12.5 g
Accessory Mount:
0.8 oz / 22.3 g | | | | Box Dimensions (LxWxH) | 6.0 x 3.8 x 2.8" | - SanDisk 64GB Extreme UHS-I microSDXC Memory Card with SD Adapter
| Card Type | microSDXC | | Storage Capacity | 64 GB | | Bus Type | UHS-I | | Speed Class | 10 | | UHS Speed Class | U3 | | Video Speed Class | V30 | | Application Performance Class | A2 | | Data Transfer | Read Speed: 160 MB/s Maximum (Burst)
Write Speed: 60 MB/s Maximum (Burst)
Write Speed: 30 MB/s Minimum | | Durability | Shockproof, Temperature Extremes, Waterproof, X-Ray Proof | | Operating Temperature | -13 to 185°F/ -25 to 85°C | | Storage Temperature | -40 to 185°F/ -40 to 85°C | | Wireless Capability | None | | | | Box Dimensions (LxWxH) | 6.5 x 4.3 x 3.7" |
