Product description The 120V 108326U Silhouette/Series E 45 x 80" Motorized Screen with LVC-IV Low Voltage Controller from Draper supports wall or ceiling installation. The sleek, curved aluminum case and endcaps are finished in white. When not in use, the screen surface and dowel retract completely inside the case. - Contrast Grey XH800E Screen Surface
- A smooth grey surface designed to accommodate high resolution images and enhance contrast and black levels in the projected image. It is recommended for use with moderate and high output digital projectors, and is suitable for use where ambient light is present. It provides a 180° viewing cone. Black backing on the other side of the viewing surface helps prevent light penetration from behind the screen. This surface is GREENGUARD Children and Schools certified
- Clean Cabling
- Conduit connection is provided at back or top
- Toolless Access
- The front fascia is removable without tools, providing easy access to roller and motor for service
Included Options - LVC-IV Low Voltage Control Module
- The LVC-IV low voltage control is used to control the screen's motor using a third-party system in a variety of ways: with a low voltage wall switch, "dry" contact closure, RF (radio frequency), IR (infrared), serial communication (such as RS-232), or low voltage relay (3-28V). It works with the separately available LVC-S, WRT, IRT/R, SP-KSM, and KS-1 Power Supply Switch. The LVC-IV is housed in a single box, features three compartments, and is UL Listed. The module contains a 3-screw terminal block for a low voltage wall switch, an IR receiver jack, a built-in RF receiver, two-RJ25 ports for RS232/RS485, a low voltage relay port with cable, and a user-serviceable 3.5A fuse
In the Box Draper 108326U Silhouette/Series E 45 x 80" Motorized Screen with LVC-IV Low Voltage Controller (120V) Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Draper 108326U Silhouette Series E 45 x 80" Motorized Screen with LVC-IV Low Voltage Controller in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDraper 108326U Specs | | | Front/Rear Projection | Front | | Aspect Ratio | 16:9 | | Style | Wall and ceiling | | | | Viewing Area | 45 x 80" / 114.3 x 203.2 cm | | Diagonal | 92" / 233.7 cm | | | | Gain | 0.8 | | Viewing Angle | 180° | | Screen Surface | Contrast Grey XH800E | | | | Motor | Standard | | Included Controls | Low voltage control |
