Product description With the 110V 118291U Ultimate Access/Series V 52 x 92" Motorized Screen with LVC-IV Low Voltage Controller from Draper, you can install the case first, and the tab-tensioned screen later. A motor-in-roller system helps ensure this screen provides quiet and smooth operation. Its ceiling-recessed design incorporates an independently motorized ceiling closure for a seamless appearance with the screen retracted. Grey XH600V Screen Surface - A grey front projection surface is designed to provide good contrast and black reproduction and is intended for use with moderate- to high-output digital projectors. Grey tolerates more ambient light in the audience area than matte white surfaces and provides a relatively broad viewing cone. This surface is GREENGUARD Children and Schools certified
Independently Motorized Closure - At the touch of a switch or wireless transmitter, the door of the Ultimate Access opens into the case before the viewing surface descends into the room
12" Drop Standard - 12" of extra drop is standard, helping ensure proper viewing height even in rooms with high ceilings
Motor-in-Roller - The motor-in-roller design helps assure quiet and smooth operation
Included Options - LVC-IV Low Voltage Control Module
- The LVC-IV low voltage control is used to control the screen's motor using a third-party system in a variety of ways: with a low voltage wall switch, "dry" contact closure, RF (radio frequency), IR (infrared), serial communication (such as RS-232), or low voltage relay (3-28V). It works with the separately available LVC-S, WRT, IRT/R, SP-KSM, and KS-1 Power Supply Switch. The LVC-IV is housed in a single box, features three compartments, and is UL Listed. The module contains a 3-screw terminal block for a low voltage wall switch, an IR receiver jack, a built-in RF receiver, two-RJ25 ports for RS232/RS485, a low voltage relay port with cable, and a user-serviceable 3.5A fuse
In the Box Draper 118291U Ultimate Access/Series V 52 x 92" Motorized Screen with LVC-IV Low Voltage Controller (110V) Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Draper 118291U Ultimate Access Series V 52 x 92" Motorized Screen with LVC-IV Low Voltage Controller in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDraper 143020FBU Specs | | | Front/Rear Projection | Front | | Aspect Ratio | 16:9 | | Style | Ceiling-recessed | | | | Viewing Area | 52.0 x 92.0" / 132.1 x 233.7 cm | | Diagonal | 106.0" / 269.2 cm | | Extra Top Drop | 12" / 30.5 cm | | | | Gain | 0.6 | | Viewing Angle | 180 degrees | | Tensioned | Yes | | | | Included Controls | Low voltage control | | | | Finish | Aluminum | | Length | 117.9" / 299.4 cm |
