Product description With the 120V 143001FNU Ultimate Access/Series V 50 x 50" Motorized Screen with LVC-IV Low Voltage Controller from Draper, you can install the case first, and the tab-tensioned screen later. A motor-in-roller system helps ensure this screen provides quiet and smooth operation. Its ceiling-recessed design incorporates an independently motorized ceiling closure for a seamless appearance with the screen retracted. - Pure White XT1300V Screen Surface
- Draper Pure White offers a 30% boost in brightness over a traditional matte white surface while still maintaining 180° viewing (90° half angle). Color does not shift when viewed from any angle, and the surface provides very good white field uniformity
- Independently Motorized Closure
- At the touch of a switch or wireless transmitter, the door of the Ultimate Access opens into the case before the viewing surface descends into the room
- 12" Drop Standard
- 12" of extra drop is standard, helping ensure proper viewing height even in rooms with high ceilings
- Motor-in-Roller
- The motor-in-roller design helps assure quiet and smooth operation
- LVC-IV Low Voltage Control Module
- The LVC-IV low voltage control is used to control the screen's motor using a third-party system in a variety of ways: with a low voltage wall switch, "dry" contact closure, RF (radio frequency), IR (infrared), serial communication (such as RS-232), or low voltage relay (3-28V). It works with the separately available LVC-S, WRT, IRT/R, SP-KSM, and KS-1 Power Supply Switch. The LVC-IV is housed in a single box, features three compartments, and is UL Listed. The module contains a 3-screw terminal block for a low voltage wall switch, an IR receiver jack, a built-in RF receiver, two-RJ25 ports for RS232/RS485, a low voltage relay port with cable, and a user-serviceable 3.5A fuse
In the Box Draper 143001FNU Ultimate Access/Series V 50 x 50" Motorized Screen with LVC-IV Low Voltage Controller (120V) Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Draper 143001FNU Ultimate Access Series V 50 x 50" Motorized Screen with LVC-IV Low Voltage Controller in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDraper 143001FNU Specs | | | Front/Rear Projection | Front | | Aspect Ratio | 1:1 | | Style | Ceiling-recessed | | | | Viewing Area | 50.0 x 50.0" / 127.0 x 127.0 cm | | Diagonal | 70.7" / 179.6 cm | | | | Gain | 1.3 | | Viewing Angle | 180 degrees | | | | Motor | Standard | | Included Controls | Low voltage control |
