User Manual for DSC Labs Fairburn 3-D Maxi Chart Click to enlarge the picture
Contents of the user manual for the DSC Labs Fairburn 3-D Maxi Chart
- Product category: Test Charts DSC Labs
- Brand: DSC Labs
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for DSC Labs Test Charts
|
User manual for the DSC Labs Fairburn 3-D Maxi Chart contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any DSC Labs product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official DSC Labs user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a DSC Labs product will considerably shorten its lifespan!
|
Product description The DSC Labs Fairburn 3-D Maxi Chart (24 x 14.7") is a calibration tool that allows videographers and filmmakers to balance and align cameras as well as check zoom, focus, rotation, keystoning and grayscale accuracy during production. Designed for a range of 3d cameras, the chart enables horizontal and vertical alignment with the help of the white cross in the center, and features a 5-pixel-wide zoom ring line to view the zoom difference between cameras focal lengths.
The RIGHT and LEFT words on the white line as well as the up and right arrows serve as orientation detectors. Additionally, the red ‘R’ and the blue ‘L’ act as color and eye reference (Red Right eye-Blue Left eye) with the red ‘R’ indicating image flip or flop orientation. Focus fans at the corners of the Fairburn 3-D chart allow for contrast adjustment, thereby ensuring that the image is easy to view even in low light conditions.
A hexagon-shaped ChromaDuMonde color reference allows you to match the vector scope orientation. In addition, the lightweight (2.4 lb / 1.1 kg) Fairburn 3-D Chart has 18% grayscale chips on the top right and left sides. - Calibration tool that allows videographers and filmmakers to balance and align cameras as well as check zoom, focus, rotation, keystoning and grayscale accuracy during production
- Designed for precise setup and post processing of a range of 3D camera systems
- Horizontal and vertical alignment with the help of the white cross at the centre
- 5-pixel-wide zoom ring line to view zoom difference between cameras focal lengths
- RIGHT and LEFT words on the white line as well as the up and right arrows serve as orientation detectors
- Red 'R' and the blue 'L' act as color and eye reference (Red Right eye-Blue Left eye) with the red 'R' indicating image flip or flop orientation
- Focus fans at the corners of the Fairburn 3-D chart allow for contrast adjustment, thereby ensuring that the image is easy to view even in low light conditions
- A hexagon-shaped ChromaDuMonde color reference to match the vector scope orientation
- 18% grayscale chips on the top right and left sides
- Lightweight (2.4 lb / 1.1 kg)
In the Box DSC Labs Fairburn 3-D Maxi Chart (24 x 14.7") 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the DSC Labs Fairburn 3-D Maxi Chart in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersDSC Labs F3DS Specs | Size | 24 x 14.7" (60.96 x 37.34 cm) | | Construction | Not specified by manufacturer | | Alignment | Horizontal & vertical | | Pixels | 5 | | Orientation | Image flip-flop orientation | | Weight | 2.4 lb (1.1 kg) | | | | Package Weight | 3.0 lb | | Box Dimensions (LxWxH) | 23.3 x 15.3 x 3.8" |
