Earthworks TC20MP Omnidirectional Condenser Microphone

Search your instruction manual in PDF to download

User Manual for Earthworks TC20MP Omnidirectional Condenser Microphone

Click to enlarge the picture
Earthworks TC20MP Omnidirectional Condenser Microphone Contents of the user manual for the Earthworks TC20MP Omnidirectional Condenser Microphone
  • Product category: Small Diaphragm Condenser Earthworks
  • Brand: Earthworks
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Earthworks Small Diaphragm Condenser

User manual for the Earthworks TC20MP Omnidirectional Condenser Microphone contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Earthworks product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Earthworks user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Earthworks product will considerably shorten its lifespan!



Product description

The TC20MP from Earthworks is a matched pair of omnidirectional microphones intended for crucial capturing of loud, transient-rich sources such as drums, percussion, amplified instruments, horns, and much more. The omnidirectional capsule exhibits fast response to transient (peak) signals.The capsule is coupled with a dedicated low output impedance preamplifier resulting in transparent signal reproduction without noise and peak distortion. An impressively wide, flat frequency response and omnidirectional pick up pattern further maximize detail and eliminate noise due to proximity effect. Overall the TC20 is a valued addition to professional and project recording facilities, as well as sound reinforcement rigs.
    Matched Pair
  • This stereo set of Earthworks TC20 microphones are perfectly matched in sensitivity and frequency response from the manufacturer. The matched pair is intended for stereo applications such as ambiance, overhead, and piano capturing.
    Ultra Wide Frequency Response
  • The TC20 exhibits a frequency response of 10 Hz to 20 kHz resulting in impressively detailed signal reproduction.
    Fast Transient Response
  • The prepolarized condenser capsule is capable of capturing signal rich in transient peaks without noise due to distortion.
    High SPL Handling
  • The TC20's high SPL provides incredible headroom which further minimizes noise due to peak distortion and excessively loud signals at close proximity.
    Omnidirectional Polar Pattern
  • The omnidirectional polar pattern provides rich, consistent detail at the off and direct sections of the capsule.
    Compact Profile
  • The TC20 shares similar features to the TC30 and TC25 except a maximum high frequency response at 20 Hz and a much smaller profile.
UPC: 827517102009 In the Box Earthworks TC20MP Omnidirectional Condenser Microphone (Matched Pair)
  • Plastic Storage Box
  • 2 x Microphone Clips
  • Frequency Response Chart
  • Limited 15-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Earthworks TC20MP Omnidirectional Condenser Microphone in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Earthworks TC20 Specs

    Polar Pattern Omnidirectional
    Frequency Range 10 Hz to 20 kHz
    Equivalent Noise Level 27 dB A-Weighted
    Maximum SPL 150 dB SPL
    Impedance 100 Ohms
    Load Impedance 600 Ohms
    Sensitivity 10 mV/Pa
    Output Connectors 1 x 3-Pin XLR
    Operating Current Consumption 10 mA
    Operating Voltage 48 V
    Length 6.5" / 165.10 mm
    Diameter 0.86" / 21.84 mm
    Weight 0.35 lb / 159 g
    Package Weight 1.45 lb
    Box Dimensions (LxWxH) 8.4 x 6.0 x 3.4"

    Rating

    70% users recommend this product to others. And what about you?
    Rating: 3.5 of 5

    This product has already been rated by 68 owners. Add your rating and experience with the product.
