Eizo FlexScan EV2456 24.1" 16:10 IPS

Search your instruction manual in PDF to download

User Manual for Eizo FlexScan EV2456 24.1" 16:10 IPS Monitor

Click to enlarge the picture
Eizo FlexScan EV2456 24.1" 16:10 IPS Monitor Contents of the user manual for the Eizo FlexScan EV2456 24.1" 16:10 IPS
  • Product category: Computer Monitors Eizo
  • Brand: Eizo
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Eizo Computer Monitors

Eizo FlexScan EV2456 24.1" 16:10 IPS Monitor Eizo FlexScan EV2456 24.1" 16:10 IPS Monitor
User manual for the Eizo FlexScan EV2456 24.1" 16:10 IPS contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Eizo product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Eizo user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Eizo product will considerably shorten its lifespan!



Product description

10 Factors to Consider When Selecting A Monitor for Video Editing Read More sddutvebzbucwcvvrezxwfuxds The Eizo FlexScan EV2456 24.1" 16:10 IPS Monitor features a 16:10 aspect ratio and 1920 x 1200 native resolution for HD performance. Four separate inputs give you maximum compatibility with almost any desktop. You get a VGA, DVI-D, HDMI, and DisplayPort connections. Built-in technology for flicker-free viewing and auto brightness adjustments help to make using this monitor in low-light settings, and for long lengths of time, a much more comfortable experience.

While it can be used in any setting, the FlexScan EV2456 offers many options that make it suitable for a corporate environment. The included stand provides a variety of physical adjustments to let you optimize setup for almost any user, and configuration software can configure multiple displays from a single monitor. Even complex multi-monitor configurations are made easier, thanks to a 1mm thin bezel, with a 5.2mm black border, that is flush with the screen's surface.
    Multiple Adjustment Options
  • Twist, tilt, and spin your FlexScan to the exact position you need it. It allows for up to 6.2" of height adjustment, and 90 degrees of rotation, left or right, offers landscape or portrait orientation. You can tilt the monitor from -5 to 35 degrees in order to better reduce glare and improve viewing angles. And quickly sharing what's on your display with others around you is a snap, thanks to its ability to swivel 344 degrees from side to side.
    Built-In 2-Port USB Hub
  • Few things are more frustrating than running out of USB ports, or having to crawl on the floor to connect a USB stick. The EV2456 provides two built-in USB 3.0 Type-A ports for convenient connection of storage devices and peripherals.
    Built-In Speakers with Headphone Jack
  • Built into the monitor are a pair of 1W speakers and 3.5mm stereo input, as well as a headphone output jack. Listen to your favorite audio without the need of additional speakers.
    Energy Efficient
  • The EV2456 has been certified in multiple standards for both visual ergonomics and energy savings. The monitor typically uses less than 13W of power, which earned it the EU Energy Label's maximum rating of A++.
    Configuration by Mouse
  • One of the many highlights of the EV2456 is the built-in Screen InStyle software that takes monitor configuration away from manual control buttons, to a more intuitive mouse-based option. Using your mouse, you can control the display's power, color, brightness, and gamma settings. You can even manage multiple connected monitors from a single display.
    Monitor Configuration for Administrators
  • EIZO Monitor Configuration lets system administrators control the settings of all FlexScan EV series monitors with a USB connection. The settings of one monitor can be saved as an XML file and applied to other monitors via USB or the office network.
    Auto Brightness Control
  • To help eliminate eye fatigue, a brightness sensor called Auto EcoView detects the changes in the ambient brightness that occurs throughout the day, and automatically adjusts the screen to the ideal brightness level.
    1 to 100% Brightness Range
  • In a dimly-lit work environment, a monitor with low brightness settings is more comfortable to use. With its LED backlight, the monitor is adjustable to 1 cd/m², which is less than 1% of the maximum.
UPC: 690592042757 In the Box Eizo FlexScan EV2456 24.1" 16:10 IPS Monitor
  • Power Cable
  • DisplayPort Cable
  • USB Cable
  • Cable Cover
  • Limited 5-Year Warranty
  • Data Sheet PDF 1.3mbsddutvebzbucwcvvrezxwfuxds Table of Contents




    Upload User Manual

    Have you got an user manual for the Eizo FlexScan EV2456 24.1" 16:10 IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Eizo FlexScan EV2456 Specs

    Size 24.1"
    Screen Area 20.41 x 12.76" / 518.4 x 324 mm
    Panel Type IPS-Type LCD
    Touchscreen No
    Resolution 1920 x 1200
    Aspect Ratio 16:10
    Pixels Per Inch (ppi) 93 ppi
    Maximum Brightness 350 cd/m2
    Contrast Ratio 1000:1
    Adaptive Sync Technology None
    Horizontal Frequency 31 to 76 kHz (DVI)
    31 to 76 kHz (DisplayPort)
    15 to 76 kHz (HDMI)
    31 to 81 kHz (VGA)
    Vertical Frequency 59 to 61 Hz (DVI)
    59 to 61 Hz (DisplayPort)
    49 to 61 Hz (HDMI)
    55 to 76 Hz (VGA)
    Bit Depth / Color Support 6-Bit+FRC (16.7 Million Colors)
    HDR Compatibility None
    Response Time 5 ms
    Viewing Angle Horizontal: 178°
    Vertical: 178°
    Dot Pitch 0.270 x 0.270 mm
    Connectivity 2 x USB Type-A (USB 3.1 Gen 1)
    1 x VGA Input
    1 x DVI-D Input
    1 x DisplayPort Input
    1 x HDMI Input
    1 x 3.5 mm Input
    1 x 3.5 mm Output
    HDCP Support Yes
    Built-In Speakers Yes, 2 x 1 W
    Supported Languages English
    French
    German
    Italian
    Japanese
    Simplified Chinese
    Spanish
    Swedish
    Traditional Chinese
    Power Consumption 11 W (Typical)
    44 W (Maximum)
    0.5 W (Eco)
    AC Input Power 100 to 240 VAC, 50 / 60 Hz
    Certifications CE, ENERGY STAR, EPEAT GOLD, FCC, RoHS, TCO Certified, TUV, WEEE, as per Manufacturer
    Height Adjustment 6.24" / 158.6 mm
    Rotation Adjustment 180° (-90 to 90°)
    Swivel Adjustment 344°
    Tilt Adjustment -5 to 35°
    Mounting-Hole Pattern 100 x 100 mm
    Lock Slot No
    Dimensions (W x H x D) 20.9 x 20.1 x 7.5" / 531.0 x 510.1 x 190.0 mm (With Stand)
    20.9 x 13.5 x 1.8" / 531.0 x 341.9 x 45.5 mm (Without Stand)
    Weight 12.6 lb / 5.72 kg (With Stand)
    8.2 lb / 3.72 kg (Without Stand)
    Package Weight 16.75 lb
    Box Dimensions (LxWxH) 24.0 x 17.75 x 9.9"
