Product description The white Electro-Voice EVID-C4.2LP is a pair of 4" coaxial flush-mount installation speakers with low-profile backcans designed for placement in tight ceiling areas and work effectively as a background music and paging solution for offices, waiting rooms, and other similar spaces.
The speaker is equipped with a line-matching transformer for 70V/100V operation and a transformer tap-selector switch that includes 8-Ohm bypass operation conveniently located on the front of the speaker. The EVID-C4.2LP provides wide dispersion, high efficiency, high-maximum output, ease of installation, and wide-range reproduction of music or voice. - 4" coaxial, 2-way installation speaker with low-profile backcan design for flush-mount placement in tight areas
- High-output speaker offers optimized reproduction of background music or paging/announcement requirements
- Full bandwidth overload protection circuitry; protects network, woofer and tweeter drivers from excessive power levels
- Waveguide coupled titanium tweeter for smooth high-frequency dispersion
- Integrated low-loss, line-matching transformer for 70V/100V or 8-Ohm bypass operation
- Front-baffle wattage selector switch allows for 1.8 (70V only) / 3.75 / 7.5 / 15 / 30W delivery to loudspeaker system when using 70V/100V lines
- Perforated grille speaker covers with powder-coated, semi-gloss white enamel finish
In the Box Electro-Voice EVID-C4.2LP - 4" Low-Profile Ceiling Speaker (Pair, White) 2 x Speaker Systems 4 x Tile Rails 2 x C-Ring Supports 2 x Grilles 4 x Support Ring Screws 2 x Terminal Connectors Cutout Template 2 x Paint Shields Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Electro-Voice EVID-C4.2LP - 4" Low-Profile Ceiling Speaker in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersElectro-Voice F.01U.351.201 Specs | Frequency Response | 60 Hz to 20 kHz | | Sensitivity | 86 dB (SPL 1 W/1 m) | | Coverage | 130° Conical | | Power Handling | 50 W at 8 Ohms (with Overload Protection) | | Rated Impedance | 8 Ohms | | High Pass Filter | 65 Hz | | Configuration Options | Input Configuration: 8 Ohms, 70 V/100 V | | Power Taps | 70 V/100 V Power Taps: 1.8 (70 V Only), 3.7, 7.5, 15, 30 W | | Transducers | LF Transducer: 4.0" / 101.6 mm High-Compliance Driver (Weatherized Cone)
HF Transducer: 0.75" / 19.05 mm Ti-Coated Dome | | Mounting System | Integrated 4-Point Toggle Anchors | | Design | Acoustic Design: Ported Cabinet, Two-Way Design, Internally Damped, with Passive Crossover | | Cabinet Construction | Steel Enclosure and UL94V-0 Rated Baffle and Bezel | | Grille | Powder-Coated Steel | | Color | White (Paintable) | | Safety Rating | UL 1480
Safe for Use in Air Handling Spaces per UL 2043 | | Dimensions | Depth and Diameter: 3.7 x 11.8" / 94.0 x 299.7 mm
Cutout Diameter: 10.6" / 269.2 mm | | Weight | 7.4 lb / 3.3 kg |
