User Manual for Electro-Voice PC Boundary Satellite Multi-Pattern Layer Microphone Click to enlarge the picture
Contents of the user manual for the Electro-Voice PC Boundary Satellite Multi-Pattern Layer
- Product category: Boundary Microphones Electro-Voice
- Brand: Electro-Voice
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Electro-Voice Boundary Microphones
|
User manual for the Electro-Voice PC Boundary Satellite Multi-Pattern Layer contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Electro-Voice product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Electro-Voice user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Electro-Voice product will considerably shorten its lifespan!
|
Product description The PC Boundary Satellite Multi-Pattern Layer Microphone from Electro-Voice is a unique and flexible boundary microphone with four user selectable polar patterns and a compartment for Telex and Electro-Voice wireless bodypack transmitters. This flexible microphone is a suitable wireless solution for discussions, conferences, boardroom meetings, houses of worship and more.The ability to use the PolarChoice Boundary Satellite with any Telex or Electro-Voice wireless system means you can choose the level of wireless performance required for your application. The transmitter simply installs into the base of the microphone and connects to the installed TA4-female connection. The four switchable patterns provide flexibility in any audio capturing scenario and the overall sound of the Boundary Satellite makes it a wise choice for crucial speech capturing in any application. - EV and Telex Wireless Compatibility
- The PolarChoice Boundary Satellite features a compartment and TA4 connection for Telex and Electro-Voice wireless bodypack transmitters.
- Four Switchable Polar Patterns
- Omnidirectional, cardioid, supercardioid and figure-eight polar patterns are provided for added flexibility.
- Variable Switch Modes
- Momentary, push-to-mute, push-on and push-off switch modes are available.
- Low-Cut Filter
- A low-cut filter switch reduces rumble, surface and other low-frequency noise.
UPC: 800549445221 In the Box Electro-Voice PC Boundary Satellite Multi-Pattern Layer Microphone Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Electro-Voice PC Boundary Satellite Multi-Pattern Layer Microphone in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersElectro-Voice F.01U.120.570 Specs | | | Transducer | Electret Condenser | | Polar Pattern | Cardioid, Figure-8, Omnidirectional, Supercardioid | | Pattern Selection | Switched | | Frequency Range | 50 Hz to 20 kHz | | Equivalent Noise Level | 26 dB A-Weighted | | Maximum SPL | 128 dB SPL | | THD | 1% | | Impedance | 1000 Ohms | | Sensitivity | 17.8 mV/Pa | | Dynamic Range | 98 dB | | | | Output Connectors | 1 x TA4F | | Operating Current Consumption | 1.9 mA | | Operating Voltage | 5 V | | Length | 5.5" / 13.97 cm | | Weight | 4.5 oz / 128 g |
