User Manual for Electro-Voice Sx-300PI - 2-Way 12" Weather-Resistant Installation P.A. Speaker - White Click to enlarge the picture
Contents of the user manual for the Electro-Voice Sx-300PI - 2-Way 12" Weather-Resistant
- Product category: PA Speakers Electro-Voice
- Brand: Electro-Voice
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Electro-Voice PA Speakers
|
User manual for the Electro-Voice Sx-300PI - 2-Way 12" Weather-Resistant contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Electro-Voice product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Electro-Voice user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Electro-Voice product will considerably shorten its lifespan!
|
Product description The Electro-Voice Sx-300PI is a 2-way, very high output, full-range loudspeaker with a 300-watt power handling capacity, designed for permanent institutional and commercial installations. The speaker features a ported, trapezoidal, weather-resistant enclosure, housing a 12" woofer and a 1" compression driver loaded into a constant-directivity horn. A selection of metric insert points has been built into the Sx-300PI, accommodating a variety of mounting and suspension options, and the cabinet is additionally equipped with an integral carrying handle and recessed 1-3/8" speaker pole mount. - 2-way, full-range 300 watts continuous, 1200 watts peak fixed installation loudspeaker in weather-resistant cabinet
- Extended HF frequency response to 25kHz, high 131dB peak SPL
- Ported enclosure with port covers for extended LF definition
- 12" woofer, 1" compression driver loaded into 65° x 65° constant-directivity horn
- HF driver protection circuitry
- RMD (Ring-Mode Decoupling) technology for optimized speech intelligibility
- Polypropylene enclosure with black powder-coated, foam-backed stainless steel grille
- Integral carrying handle and stand socket, dual professional paralleled Neutrik NL4 Speakon cable connectors
- Multiple mounting and suspension options
UPC: 800549682367 In the Box Electro-Voice Sx-300PI - 2-Way 12" Weather-Resistant Installation P.A. Speaker - White 4 x Plastic Port Covers 4 x M8 Metric Inserts 5 Year Warranty User Manual PDF 263.8kb Table of Contents
|
Upload User Manual
Have you got an user manual for the Electro-Voice Sx-300PI - 2-Way 12" Weather-Resistant Installation P.A. Speaker - White in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersElectro-Voice Sx300PI Specs | | | Configuration | Passive 2-Way | | Total Power Capacity | 300 W | | System Impedance | 8 Ohms | | | | HF Driver | 1 x 1" / 51 mm Horn-Loaded Compression Driver | | LF Driver | 1 x 12" / 305 mm Woofer | | | | Frequency Response | 80 Hz to 25 kHz (Port Open)
90 Hz to 25 kHz (Port Closed) | | Maximum SPL | 131 dB | | Speaker Sensitivity | 99.5 dB SPL | | | | Audio I/O | 1 x speakON Input | | | | Crossover | 1.5 kHz, 12 dB/Octave | | | | Construction Material | Metal Grille, Polystyrene | | Dimensions | 23.1 x 16.9 x 12.3" / 586.0 x 429.0 x 312.0 mm | | Weight | 40 lb / 17.7 kg | | | | Package Weight | 39.7 lb | | Box Dimensions (LxWxH) | 24.5 x 22.0 x 13.8" |
