Elo Touch 2201L 22" 16:9 PCAP

Search your instruction manual in PDF to download

User Manual for Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor

Click to enlarge the picture
Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor Contents of the user manual for the Elo Touch 2201L 22" 16:9 PCAP
  • Product category: Computer Monitors Elo Touch
  • Brand: Elo Touch
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Elo Touch Computer Monitors

Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor
User manual for the Elo Touch 2201L 22" 16:9 PCAP contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Elo Touch product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Elo Touch user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Elo Touch product will considerably shorten its lifespan!



Product description

10 Factors to Consider When Selecting A Monitor for Video Editing Read More The Elo Touch 2201L 22" 16:9 Touchscreen incorporates zero-bezel PCAP (projected capacitive) multi-touch technology and offers a maximum resolution of 1920 x 1080. With a brightness rating of 250 cd/m2 and contrast ratio of 1,000:1, it is suitable for front-of store, back office, kiosk, and out-of-store applications. The monitor comes with USB, DVI, and VGA interfaces and built-in speakers.The monitor is compatible with Windows 7 and 8 operating systems and provides stable, “drift-free” operation with improved image clarity and light transmission for accurate touch response and vivid images.

Performance

  • Zero-bezel PCAP multi-touch Touchscreen technology
  • Offers a maximum resolution of 1920 x 1080 and contrast ratio of 1,000:1
  • USB touch controller, DVI, and VGA
  • Built-in 2W speakers
  • Removable base
  • VESA 100mm mounting interface on rear of unit
  • Ruggedized for use in high-traffic environments
  • Optional peripherals include a field-installable 3-stripe MSR and web camera

Applications

  • Point-of-information
  • Promotion of cross-channel, online sales in the store
  • Hostess stations that require large screens to view restaurant layouts/seating charts
  • Back office solutions integrating labor management and inventory analysis
  • Customer assist and self-service solutions (theaters, hotels, auto, and dealerships)
  • Shelf-level/countertop interactive digital signage displays
  • HD video capabilities for interactive lifestyle marketing in larger retail/lifestyle stores
UPC: 741149331050 In the Box Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor
  • External Power Adapter
  • Detachable touch, Audio, Power, and Video Cables
  • Limited 3-Year Warranty
  • Guides & Manuals Table of Contents




    Upload User Manual

    Have you got an user manual for the Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:


    User manual for Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor can be downloaded below, so the upload option is not active.


    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%

    User manual for Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor can be downloaded below, so the upload option is not active.

    Download User Manual

    The user manual for the Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor can be downloaded in PDF format at the link stated below.
    Download PDF user manual - Elo Touch 2201L 22" 16:9 PCAP Touchscreen MonitorDownload PDF User Manual - Elo Touch 2201L 22" 16:9 PCAP Touchscreen Monitor
    (PDF file, 0.22 MB)


    Technical parameters

    Elo Touch E497002 Specs

    Size 21.5"
    Screen Area 18.8 x 10.6" / 47.7 x 26.8 cm
    Touchscreen Yes
    Resolution 1920 x 1080
    Aspect Ratio 16:9
    Maximum Brightness 250 cd/m2
    Contrast Ratio 1000:1
    Horizontal Frequency 31.5 to 80 kHz
    Vertical Frequency 50 to 75 Hz
    Bit Depth / Color Support 8-Bit (16.7 Million Colors)
    Response Time 5 ms
    Viewing Angle Horizontal: °
    Vertical: °
    Backlight Lifespan 50,000 Hours
    Connectivity 1 x 3.5 mm Input/Output
    1 x 3.5 mm Output
    1 x DVI-D
    1 x VGA
    Built-In Speakers Yes, 2 x 2 W
    Power Consumption 29 W (Typical)
    AC Input Power 100 to 240 VAC, 50 / 60 Hz
    Operating Temperature 32 to 104°F / 0 to 40°C
    Storage Temperature -4 to 140°F / -20 to 60°C
    Operating Humidity 20 to 80%
    Storage Humidity 10 to 90%
    Certifications RoHS, WEEE, as per Manufacturer
    Mounting-Hole Pattern 100 x 100 mm, 200 x 200 mm
    Lock Slot Yes
    Dimensions (W x H x D) 21.7 x 7.6 x 15.4" / 55.1 x 19.3 x 39.2 cm
    Weight 16.5 lb / 7.5 kg
    Package Weight 22.0 lb
    Box Dimensions (LxWxH) 24.5 x 18.75 x 11.25"

    Rating

    60% users recommend this product to others. And what about you?
    Rating: 3 of 5

    This product has already been rated by 79 owners. Add your rating and experience with the product.
