Encore Punch! ViaCAD 2D 3D v9

User Manual for Encore Punch! ViaCAD 2D 3D v9 for Windows

• Product category: Animation & CAD Software Encore
• Brand: Encore
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Encore Animation & CAD Software

Product description

Types of Projects You Can Create:
• • 3D models for prototyping with 3D printers
  • Mechanical parts
  • DIY projects: 3D models of furniture and work benches
  • Architectural drawings for drafting documents, room layouts, and 3D visualization
  • Educational: Drawings and 3D models for science fairs
  • Objects for use in game development studios

Intelligent Drawing Tools

• The LogiCursor aids in precise drawing using your mouse by aligning your cursor with existing points in your drawing

• The Gripper tool provides click and drag style editing for moving, copying, scaling, and rotating parts of the drawing, even faces

• Push/Pull Modeling delivers intuitive editing of your 3D models, allowing 3D surfaces to be edited with your mouse and cursor

• Customizable Grids can be configured as rectangular, polar (circular), and even isometric

• 26,000 symbols are included to speed up your designing

Solid Modeling

• A link between 2D and 3D variants means you can edit 2D profiles used to create 3D objects and the 3D shape will automatically update

• Feature-based History Tree for editing

• 3D editing tools, including blending, chamfering, and shelling

• A complete design tool with extrusions, Booleans, and surface modeling for more complex smooth surfaces

• Precise geometry suitable for "concept-to-manufacturing"

• The ability to create a 3D object from 2D shapes

Over 250 2D Drawing and Editing Tools

• Each drawing tool has multiple options for creating objects in your designs. Tools such as rectangular and polar (circular) arrays help you create more precise and complicated patterns. A complete toolkit of trimming options is available to help you make modifications. These tools include:

• Points, Lines, Arcs, Circles, Ellipses, Splines

• Copy/Move, Scale, Rotate, Mirror, Stretch

• Rectangular array with X and Y controls

• Polar (circular) array with customizable angles and spacing

• Trimming tools including Trim, Extend, and Break

• Customizable Fillet and Chamfer

Drafting and Annotations

• Supports 20 customizable dimension styles, including industry dimension formats

• Import a 3D model and the Auto 3D to 2D feature will create multiple 2D views to document 3D models created in other software

• Import bitmaps for logos and reference images

• 26 dimension styles

• Spell Check provided

• Single click Fills and Hatch

Architectural

• Create scaled building drawings and room layouts

• Custom walls are drawn using thicknesses based on different components allowing you to present the real-world wall sizes and construction materials

• Walls are automatically trimmed at intersections

• Custom wall components allow you to differentiate interior and exterior walls visually

• Insert intelligent doors and windows with "drag and drop" placement

• Instant architectural detailing with automatic dimensioning or customize your own labels for doors and windows with callouts

Compatibility and Sharing

• Supports AutoCAD and other third-party formats

• DXF/DWG type files - versions R12 through 2013

• Complete support for metric and imperial units

• Supports IGES, STEP, and SAT type files

• STL import and export

• Interoperability with Adobe Illustrator files
