Product description Punch! ViaCAD 2D v9 for Windows from Encore is an electronically downloaded drafting and design application that features over 250 drawing tools. It is designed to suit a diverse range of 2D drawing applications, from simple sketches or jotting ideas to full-fledged, production-ready documents. It can import and export many third-party formats and can import 3D files for conversion to multiple 2D images. - Types of Drawings You Can Create:
-
- Mechanical detail drawings
- Scaled graphics for illustrations in presentations and documentation
- Schematics: Electrical, Electronic, Piping, Flow charts, and more
- DIY projects: Plans for home projects such as building workbenches and furniture
- Architectural: Draw building layouts and furniture plans
- Plans for inventions and ideas
Intelligent Drawing Tools - The LogiCursor guides your cursor to potential point selections in the drawing; anticipating your next action
- The Gripper tool provides drag and drop style editing
- Customizable grids provide precision drag and drop in rectangular, polar (circular), and isometric layouts
- The Drawing SetUp wizard walks you through setting up the drawing space
- Custom tool palettes let you configure the workspace that best suits your project
- Unlimited Undo and Redo functionality provided
Over 250 Drawing and Editing Tools - Each drawing tool has multiple options for creating objects in your designs. Tools such as rectangular and polar (circular) arrays help you create more precise and complicated patterns. A complete toolkit of trimming options is available to help you make modifications. These tools include:
- Points, Lines, Arcs, Circles, Ellipses, Splines
- Copy/Move, Scale, Rotate, Mirror, Stretch
- Rectangular array with X and Y controls
- Polar (circular) array with customizable angles and spacing
- Trimming tools including Trim, Extend, and Break
- Customizable Fillet and Chamfer
Drafting and Annotations - Supports 20 customizable dimension styles, including industry dimension formats
- Import a 3D model and the Auto 3D to 2D feature will create multiple 2D views to document 3D models created in other software
- Import bitmaps for logos and reference images
- Single click Fills and Hatch
Architectural - Create scaled building drawings and room layouts
- Custom walls are drawn using thicknesses based on different components allowing you to present the real-world wall sizes and construction materials
- Walls are automatically trimmed at intersections
- Custom wall components allow you differentiate interior and exterior walls visually
- Insert intelligent doors and windows with "drag and drop" placement
- Instant architectural detailing with automatic dimensioning or customize your own labels for doors and windows with callouts
Compatibility and Sharing - Supports AutoCAD and other third-party formats
- DXF/DWG type files - versions R12 through 2013
- Complete support for Metric and Imperial units
- Supports IGES, STEP, and SAT type files
- Interoperability with Adobe Illustrator files
