Product description The Ensemble Design BrightEye 21 is an audio embedder for SDI digital video signals. This device will input a digital audio signal to an SDI video signal. Note: Power Supply Purchased Separately - Audio Capability
- Four AES audio channels can be embedded into the SDI video stream.
- Adjustable
- Audio mixing, level adjustments and channel shuffling can be accomplished in both modes.
In the Box Ensemble Designs BrightEye 21 Audio Embedder - SDI, Digital Audio, BNC Connections 5 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Ensemble Designs BrightEye 21 Audio Embedder - SDI, Digital Audio, BNC Connections in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersEnsemble Designs BrightEye 21 Specs | Input | SDI Video, SMPTE 259, on a BNC connector
AES/EBU Audio x2, 2+2 channels, AES3id, @ 75 ohms, on BNC connectors
PC or Mac Connectivity, on a USB connector | | Output | SDI Video, SMPTE 259, with embedded audio, on a BNC connector | | Processes | Embedding Digital Audio on an SDI Digital Video Signal Stream | | Control | Front Panel or Remote Computer Via USB:
Embed
Signal Level Adjustment
Channel Selection | | Power Source | 12 VDC from an external power source (not included) | | Dimensions (WxHxD) | 5.625 x 0.8 x 5.5"
14.3 x 2 x 14cm | | Weight | Not Specified by Manufacturer |
