Product description The BrightEye 72 HD/SD Digital to Analog Video Converter & Audio Dis-Embedder from Ensemble Designs is a digital to analog video converter and processor. This device accepts an HD/SD SDI signal and converts this signal to output a three wire analog video signal with analog audio. Note: Please note that a power supply is not included with the unit and must be purchased separately. - Digital to Analog Video Converter & Analog Audio Disembedder
- Use this device to convert SDI video to analog three wire while disembedding digtial audio for analog output.
- HDMI
- An HDMI digital output is offered for monitoring capability.
- Controls
- The unit can be controlled through the push buttons on the converter's faceplate or through the proprietary software package included with the unit.
- OS Compatibility
- The converter will work on both Windows and Mac operating systems.
In the Box Ensemble Designs BrightEye 72 HD/SD Digital to Analog Converter Converter 5 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Ensemble Designs BrightEye 72 HD SD Digital to Analog Converter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersEnsemble Designs BrightEye 72 Specs | Inputs | SDI Digital Video, HD and SD, Various Formats, Embedded Audio, on a BNC Connector | | Outputs | Analog High Resolution Video, RGB, HD RGB, YPrPb, Composite, Y/C, on three BNC Connectors
Digital Audio/Video, Monitoring Output, on an HDMI connector
Analog Audio on Crimp Connectors
Interface, USB Connector | | Conversion | SDI 1.485 Gb/s HD Serial Digital (SMPTE 274M, 292M or 296M) 3 Gb/s HD Serial Digital (SMPTE 424M, 425M) SD Serial Digital (270 Mb/s SMPTE 259M-C) with Embedded Audio to Analog Component RGB, HD RGB, YPbPr, Composite, Y/C and Analog Audio | | Power | 12VDC from AC Power Adapter
Adapter Not Included | | Dimensions (HxWxD) | 0.8 x 5.625 x 5.5"
20 x 143 x 140mm | | Weight | Not Specified by Manufacturer | | | | Package Weight | 1.25 lb | | Box Dimensions (LxWxH) | 8.7 x 7.9 x 2.4" |
