User Manual for ETC Selador Desire D60 Lustr LED Fixture with TwistLock Connector Click to enlarge the picture
Contents of the user manual for the ETC Selador Desire D60 Lustr LED
- Product category: Stage & Studio ETC
- Brand: ETC
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ETC Stage & Studio
|
User manual for the ETC Selador Desire D60 Lustr LED contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ETC product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ETC user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ETC product will considerably shorten its lifespan!
|
Product description The black Selador Desire D60 Lustr+ LED Fixture with TwistLock Connector from ETC combines 60 Luxeon Rebel LED emitters in one unit, to provide powerful, high-intensity light output. This round, PAR-shaped washlight is well-suited for stage, studio and anywhere brightness and color flexibility are required.
It comes with the Lustr+ color array that uses the premise of the x7 Color System to create lush white and subtly tinted light that can be adjusted to naturally illuminate on-stage talent or scenery. The x7 luminaires blend up to 7 LED hues to provide a nearly unlimited number of color mixes. You get additional options from the Adaptive Control System built into the luminaire. You select the DMX profile such as Calibrated HSI, Calibrated RGB, Calibrated HSIC, Studio, or Direct, and your luminaire adapts its color and functionality to each application. You have additional control with the Plus 7 setting, which allows you to tweak each LED color individually, and the fixture’s Red Shift function imitates the fade of a tungsten source.
The Selador x7 Color System produces a wide range of spectrally balanced, saturated, and tinted color choices that will satisfy even the discerning theatrical lighting designer. A rugged, die-cast enclosure, noiseless fan-cooled operation, multiple lens options, and advanced user interface make this fixture suitable for multiple applications
The luminaire features a user interface with Quick Setup options to simplify work. You can choose from Stage, High-Impact, XT (Exterior)/Architectural, General and Studio settings to customize the luminaire to your specific task. You can further tailor the fixture to your needs by choosing profile and performance settings via the user interface. The luminaire can be controlled from a DMX-enabled controller, like an ETC lighting control console, or can be run on its own by selecting the Stand Alone Mode on the unit.
- 60 Luxeon Rebel LED emitters provide high intensity light.
- The x7 Color System blends up to seven LED hues to provide a nearly unlimited number of color mixes.
- IP20 rated for indoor use
- DMX512 in and thru via 5-Pin XLR
- User-friendly control interface with multiple modes and fixture settings
- Rugged, die-cast all-metal housing
- Easy access slots for secondary lenses and accessories
- Up to 9 fixtures (15A maximum) can be linked via power in and thru connectors
- Requires power from a non-dim source
- 50,000-hour LED life (50,000 hours to 70% intensity)
- Broad spectrum color seamlessly interacts with conventional sources
- Exclusive optional red-shift option emulates tungsten dimming performance characteristics
- Multiple control options including RGB, strobe, and console-free Master/Slave mode
- 15-bit virtual dimming engine provides smooth, high quality theatrical fades and minimizes color shift during dimming
- RDM functionality for address and setting changes
- Active electronic thermal management for droop-free operation
- Luminaire is designed for continuous operation up to 104°F (40°C) ambient temperature and requires free airflow around fixture housing
- UL 1573-rated for stage and studio use
In the Box ETC Selador Desire D60 Lustr+ LED Fixture with TwistLock Connector (Black) Hanging Yoke Very Narrow Secondary Lens 5' PowerCon to Grounded 20-A Twislock Connector Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ETC Selador Desire D60 Lustr LED Fixture with TwistLock Connector in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersETC D60 Lustr Specs | Rating | D60 Lustr+ at 3,200 K
CRI: 86
CQS: 88
Color Fidelity: 88
D60 Lustr+ at 5,600 K
CRI: 93
CQS: 92
Color Fidelity: 92 A Duv rating of 0.000 indicates that the color mix used is exactly on the black body line, with no green or magenta tint. | | Mode | Boost-Cold:
Degree: 16°
Candela: 195,012
Field Lumens: 4,317
Beam Lumens: 1,931
Lumens Per Watt: 33.3
Regulated:
Degree: 16°
Candela: 180,097
Field Lumens: 3,850 Beam Lumens: 1,748
Lumens Per Watt: 32.7 | | Illuminance | 19,676 lux (1,828 fc) @ 10.0' (3.0 m) throw distance & 2.9' (0.9 m) field diameter
8,745 lux (812 fc) @ 15.0' (4.6 m) throw distance & 4.3' (1.3 m) field diameter
4,919 lux (457 fc) @ 20.0' (6.1 m) throw distance & 5.8' (1.8 m) field diameter
3,148 lux (292 fc) @ 25.0' (7.6 m) throw distance & 7.2' (2.2 m) field diameter
10.76 lux (1 fc) @ 427.6' (130.3 m) throw distance | | Color Temperature | At 3,200 K
CQS: 88
CRI: 86
At 5,600 K
CQS: 92
CRI: 93 | | | | Sound Pressure | Level: @ 30% fan speed: 25.0 dBa
@ 51% fan speed: 37.4 dBa
@ 60% fan speed: 38.6 dBa
@ 100% fan speed: 43.1 dBa | | Power Input | 100 to 240 VAC, 50/60 Hz Universal power input | | Power Consumption | Maximum: 161 W, 1.35 / 0.68 A at 120/ 240 V
Idle Power / Current: @ 100 V: 7.3 W / 0.1 A
@ 120 V: 7.4 W / 0.77 A
@ 240 V: 9 W / 0.086 A
100% Boost Power / Current: @ 100 V: 143 W / 1.46 A
@ 120 V: 140.1 W / 0.97 A
@ 240 V: 135.1 W | | Field Angle | 17° (primary) | | Beam Angle | 8° | | Ambient Operating Temperature | -4 to 104°F (-20 to 40°C) | | Dimensions (W x H x D) | Overall: 12. 2 x 14.2 x 11.4" (309.0 x 361.0 x 290.0 mm) | | Weight | 19.1 lb (8.7 kg) | | | | Box Dimensions (LxWxH) | 21.5 x 15.0 x 12.5" |
