User Manual for ETC Selador Desire D60 Studio Tungsten Luminaire with Stage Pin Connector Click to enlarge the picture
Contents of the user manual for the ETC Selador Desire D60 Studio Tungsten
- Product category: Stage & Studio ETC
- Brand: ETC
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ETC Stage & Studio
|
User manual for the ETC Selador Desire D60 Studio Tungsten contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ETC product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ETC user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ETC product will considerably shorten its lifespan!
|
Product description The white Selador Desire D60 Studio Tungsten Luminaire with Stage Pin Connector from ETC uses high-output, Tungsten-Balanced LEDs to create a fixture suitable for video, film, and other white light only applications where color temperature and skin-tone rendering are critical. It offers a rugged die-cast enclosure, quiet, fan-cooled operation, multiple lens options, and an advanced user interface that enables easy configuration and specific features for video and film professionals.The fixture can be configured to operate under control of a studio lighting control desk or via standalone, no console required settings for location lighting. The D60 Studio Tungsten contains sixty energy-saving 3000 K LEDs for high-intensity, non-variable warm-white output. It provides an enhanced color rendering to the eye, particularly at high color temperature settings.The Studio Tungsten features the all-white Luxeon Rebel ES LEDs and outputs large quantities of white light while using a mere 161W of power. The Studio Tungsten array produces warm, white light with a 3000 K color temperature. Note: All LED sources experience some lessening of light output and color shift over time. LED output varies with thermal conditions. Ambient temperatures and orientation affect thermal conditions. Based on the LED manufacturer's B50 l70 specification, a Selador luminaire will achieve approx. 70% of its initial output after 50,000 hours of typical usage. In individual situations, LEDs are used for different durations and levels, which may eventually lead to minor alterations in color performance, necessitating slight adjustment to presets, cues or programs. - 60 LED variable white light wash fixture
- IP20-rated for indoor use
- Power and DMX In / Through connections for easy setup (DMX512 in and through via 5-pin XLR connectors)
- User-friendly control interface with multiple modes and fixture settings for console-free operation
- Rugged die-cast all-metal housing
- Easy access slots for secondary lenses and accessories
- Up to 9 fixtures can be linked via power in/thru connectors per 15A circuit using 1.0mm2 cables as supplied
- Requires power from a non-dim source
- Studio Tungsten's red-shift option emulates tungsten dimming performance characteristics
- Fixture comes with a 25° lens
- Multiple control options including strobe and console-free Master / Slave mode
- 15-bit virtual dimming engine provides smooth, high quality theatrical fades
- RDM functionality for address and setting changes
- Active electronic thermal management for droop-free operation
- Low-noise fan cooling; the fan is thermostatically controlled to run as needed with 60% speed at high intensities in room temperature
- Fixture is designed for continuous operation up to 104°F (40°C) ambient temperature and requires free flow of air around fixture housing
- The fixture uses Luxeon Rebel ES emitters specified by strict binning standards
- Studio control mode allows fixtures to be operated with no DMX console required
In the Box ETC Selador Desire D60 Studio Tungsten Luminaire with Stage Pin Connector (White) Hanging Yoke 25° Secondary Lens Stage Pin Connector Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ETC Selador Desire D60 Studio Tungsten Luminaire with Stage Pin Connector in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersETC D60 Studio Tungsten Specs | Power Input | 100 to 240 VAC 50/60 Hz, universal power input | | Power Consumption | 161 W, 1.35/0.68 A, 120/240 V at full intensity | | LED Life | 50,000 hour LED life (to 70% intensity) | | Emitter | LED: 60 Luxeon Rebel 2.5 W | | Field Angle | Primary: 17°
Native: 18° | | Rating | At 3,000 K
CRI: 86
CQS: 86
Color Fidelity: 86
Duv: 0.001 | | Mode | Boost - Cold:
Degree: 23Ë¿
Candela: 139,545
Field Lumens: 6,158
Beam Lumens: 2,850
Lumens Per Watt: 43.2
Regulated:
Degree: 23Ë¿
Candela: 119,580
Field Lumens: 5,271
Beam Lumens: 2,430
Lumens Per Watt: 39.6 | | Illuminance | 15,020 lux (1,395 fc) @ 10.0' (3.0 m) throw distance & 4.1' (1.3 m) field diameter
6,676 lux (620 fc) @ 15.09' (4.60 m) throw distance & 6.23' (1.90 m) field diameter
3,755 lux (349 fc) @ 20.01' (6.10 m) throw distance & 8.30' (2.50 m) field diameter
2,403 lux (223 fc) @ 24.93' (7.60 m) throw distance & 10.50' (3.20 m) field diameter | | Broadcasting System | Acoustal:
Speed: 30%; Sound Pressure Level: 25.0 dBA
Speed: 51%; Sound Pressure Level: 37.4 dBA
Speed: 60%; Sound Pressure Level: 38.6 dBA
Speed: 100%; Sound Pressure Level: 43.1 dBA | | Operating Temperature | -4 to 104°F (-20 to 40°C) | | Overall Dimensions | 9.80 x 11.42 x 12.17" (249.00 x 290.00 x 309.00 mm) | | Weight | 19.18 lb (8.70 kg) | | | | Box Dimensions (LxWxH) | 21.5 x 15.0 x 12.5" |
