User Manual for ETC Selador Desire D60 Vivid LED Fixture with Bare Power Lead Click to enlarge the picture
Contents of the user manual for the ETC Selador Desire D60 Vivid LED
- Product category: Stage & Studio ETC
- Brand: ETC
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ETC Stage & Studio
|
User manual for the ETC Selador Desire D60 Vivid LED contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ETC product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ETC user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ETC product will considerably shorten its lifespan!
|
Product description The black Selador Desire D60 Vivid LED Luminaire with Bare Power Lead from ETC combines sixty energy-saving LED emitters in a single unit to provide powerful, high-intensity output. The Desire D60 Vivid luminaires pair the brightest LED emitters with the most vibrant color range. This round, PAR-shaped washlight is well-suited for stage, studio, and anywhere brightness and color flexibility are required. The D60 Vivid Luminaire also features the x7 Color System array. The x7 Color System uses seven different LED colors to achieve true, usable broad-spectrum color. The D60 Vivid luminaire blends up to 7 LED hues to provide a nearly unlimited number of color mixes. The D60 Luminaire features a user interface with Quick Setup options to simplify work. You can choose from Stage, High-Impact, XT (Exterior) / Architectural, General, and Studio settings to customize the luminaire to your specific task. You can further tailor the fixture to your needs by choosing profile and performance settings via the user interface. The luminaire can be controlled from a DMX-enabled controller, like an ETC lighting control console, or can be run on its own by selecting the Stand Alone Mode on the unit.The Desire D60 Vivid Luminaire pairs bright LED emitters with a vibrant color range to produce a spectrally balanced saturated light. It can be used in applications such as theatres, studios, schools, houses of worship, hotels, convention centers, theme parks, museums, temporary events, etc. Note: All LED sources experience some lessening of light output and color shift over time. LED output will vary with thermal conditions. Ambient temperatures and orientation affect thermal conditions. Based on the LED manufacturer's B50 l70 specification, a Selador luminaire achieves approximately 70% of its initial output after 50,000 hours of typical usage. In individual situations, LEDs will be used for different durations and at different levels, which may eventually lead to minor alterations in color performance, necessitating slight adjustment to presets, cues or programs. - IP-20 rated for indoor use
- DMX512 in and thru via 5-pin XLR connectors
- User-friendly control interface with multiple modes and fixture settings
- Primary field angle of 17°
- Full 7-color x7 LED array
- Optimized for high-output deep pastels and strong saturated colors; an all-around workhorse for vibrant color washes
- Rugged die-cast aluminum construction
- Easy-access slots for secondary lenses and standard 8.875" accessories
- Advanced thermal management systems for long LED life
- Ultra-quiet cooling fan for use in high ambient temperature situations; the fan is thermostatically controlled to run as needed
- Neutrik power in and thru connections
- Up to nine D60 fixtures (15A maximum) can be linked via the power thru connector
- Requires power from a non-dim source
- Achieves 3200 K or any other Correlated Color Temperature white light from 2,000 to 10,000 K
- Beautifully illuminates skin tones and other objects for natural appearance and high color rendering
- Red-shift option emulates tungsten dimming performance
- Deeply saturated colors across a wide gamut
- DMX-based fan control for predictable noise levels
- Multiple control options including RGB, strobe, and console-free master/slave mode
- 15-bit virtual dimming engine for smooth, high-quality theatrical fades and minimizes color shift during dimming
In the Box ETC Selador Desire D60 Vivid LED Fixture with Bare Power Lead (Black) Hanging Yoke Very Narrow Secondary Lens Bare End Power Lead Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ETC Selador Desire D60 Vivid LED Fixture with Bare Power Lead in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersETC D60 Vivid Specs | Power Input | 100 to 240 VAC 50/60 Hz, universal power input | | Maximum Power Consumption | 161 W, 1.35/0.68 A, 120/240 V at full intensity | | LED Life | 50,000 hours | | Emitter | 60 Luxeon Rebel LED | | Field Angle | Primary: 17° | | Rating | At 3,200 K
CRI: 87
CQS: 89
Color Fidelity: 89
Duv: 0.000
At 5,600 K
CRI: 90
CQS: 92
Color Fidelity: 92
Duv: 0.000 A Duv rating of 0.000 indicates that the color mix used is exactly on the black body line, with no green or magenta tint. | | Mode | Boost-Cold:
Degree: 17°
Candela: 170,540
Field Lumens: 3,760
Beam Lumens: 1,667
Lumens/W: 28.8
Regulated:
Degree: 17°
Candela: 132,451
Field Lumens: 3,050
Beam Lumens: 1,305
Lumens/W: 28.3 | | Illuminance | 17,405 lux (1,617 fc) @ 10.0' (3.0 m) throw distance & 3.0' (0.9 m) field diameter
7,736 lux (719 fc) @ 15.0' (4.6 m) throw distance & 4.5' (1.4 m) field diameter
4,351 lux (404 fc) @ 20.0' (6.1 m) throw distance & 5.9' (1.8 m) field diameter
2,785 lux (259 fc) @ 25.0' (7.6 m) throw distance & 7.4' (2.3 m) field diameter
10.76 lux (1 fc) @ 402.1' (122.6 m) throw distance | | Fan Noise | Acoustal:
Speed: 30%; Sound Pressure Level: 25.0 dBA
Speed: 51%; Sound Pressure Level: 37.4 dBA
Speed: 60%; Sound Pressure Level: 38.6 dBA
Speed: 100%; Sound Pressure Level: 43.1 dBA | | Operating Temperature | 32 to 104°F (0 to 40°C)
Continuous operation at 104°F (40°C) | | Overall Dimensions (H x W x D) | 14.2 x 12.2 x 11.4" (361.0 x 309.0 x 290.0 mm) | | Weight | 19.1 lb (8.7 kg) | | | | Box Dimensions (LxWxH) | 21.5 x 15.0 x 12.5" |
