User Manual for EVGA SuperNOVA 650 G1 Power Supply Click to enlarge the picture
Contents of the user manual for the EVGA SuperNOVA 650 G1 Power Supply
- Product category: Power Supplies EVGA
- Brand: EVGA
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for EVGA Power Supplies
|
User manual for the EVGA SuperNOVA 650 G1 Power Supply contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any EVGA product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official EVGA user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a EVGA product will considerably shorten its lifespan!
|
Product description The SuperNOVA 650 G1 Power Supply from EVGA is designed to use with 4th generation Intel Core processors. It is an 80 PLUS Gold certified and provides up to 90% efficiency under typical loads. The power supply is equipped with a 135mm double ball-bearing fan for cooling. - 80 PLUS Gold certified, with up to 90% efficiency under typical loads
- Fully modular to reduce clutter and improve airflow
- 135mm double ball-bearing fan for cooling
- Designed to use with 4th generation Intel Core processors (C6/C7 Idle Mode)
UPC: 843368030919 In the Box EVGA SuperNOVA 650 G1 Power Supply Limited 10-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the EVGA SuperNOVA 650 G1 Power Supply in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersEVGA 120-G1-0650-XR Specs | Total Connectors | 1 x 24-Pin Motherboard 2 x 4+4-Pin EPS 4 x 6+2-Pin PCIe 9 x 15-Pin SATA 6 x 4-Pin Peripheral / Molex 1 x 4-Pin Floppy | Cable Design | Modular | PCIe Connector Distances | 23.6" / 600 mm 29.5" / 750 mm | SATA Connector Distances | 17.7" / 450 mm 21.6" / 550 mm 25.5" / 650 mm 29.5" / 750 mm | Peripheral Connector Distances | 21.7" / 550 mm 25.6" / 650 mm 29.5" / 750 mm 33.4" / 850 mm | Floppy Connector Distances | 29.5" / 750 mm | ATX Connector Distance | 23.6" / 600 mm | EPS Connector Distances | 23.6" / 600 mm 29.5" / 750 mm | | Number of +12 V Rails | 4 | Combined Power for +12 V | 636 W | Max Load for +12 V | 20 A | Combined Power for +3.3/+5 V | 150 W | Max Load for +3.3 V | 25 A | Max Load for +5 V | 25 A | Max Power for +5 Vsb | 15 W | Max Load for +5 Vsb | 3 A | Max Power for -12 V | 9.6 W | Max Load for -12 V | 0.8 A | AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 5 to 10 A | | Efficiency Rating | None | Efficiency | 90% | | Fan Size | 135 mm | Bearing Type | Ball | | Operating Temperature | 32 to 122°F / 0 to 50°C | | Certifications | RoHS, WEEE, as per Manufacturer | Mean Time Between Failures (MTBF) | 100,000 Hours | Power Cable Length | 5.9' / 1.8 m | Dimensions | 7.0 x 5.9 x 3.3" / 180.0 x 150.0 x 85.0 mm | Weight | 8.0 lb / 3.6 kg | | Package Weight | 7.35 lb | Box Dimensions (LxWxH) | 12.441 x 10.315 x 5.039" |
Rating98% users recommend this product to others. And what about you?
This product has already been rated by 63 owners. Add your rating and experience with the product.
