Product description The Z390 FTW LGA 1151 ATX Motherboard from EVGA is built on the Intel Z390 chipset supporting 8th and 9th generation Intel Core processors with a LGA 1151 socket. It has four memory slots for up to 64GB of 4133 MHz DDR4 RAM, six SATA III ports, two M.2 slots, as well as two PCIe x16, one PCIe x4, and two PCIe x1 slots. Aside from standard M.2 SSDs, the M.2 slots also support Intel Optane Memory to help improve system performance. With two PCIe x16 slots, this motherboard can be used for two-way NVIDIA SLI setups. Other integrated features include multiple USB ports, audio jacks, Intel i219V Gigabit LAN, and Realtek ALC1220 7.1-channel HD audio. If needed, it also has an E-key M.2 slot for an optional Wi-Fi and Bluetooth module.
Please note that Intel Kaby Lake-S CPUs only support Windows 10 whereas Skylake CPUs support Windows 7, 8, and 10. -
- Efficient 11-phase digital VRM design
- Intel Optane Memory ready
- Realtek 7.1-channel HD audio with EVGA NU audio
- RGB header support
- Increased gold content in CPU socket
- 100% solid state capacitors
- Reinforced PCIe and DIMM slots
- Onboard Clear CMOS, Power, and Reset buttons
- Onboard CPU temperature monitor
- SPI flashing via USB (no CPU needed)
- Optional EVGA E-LEET Tuning software
UPC: 843368053376 In the Box EVGA Z390 FTW LGA 1151 ATX Motherboard I/O Shield SLI Bridge 2 x SATA Cables Limited 3-Year Warranty Spec sheet PDF 2.2mbzffsvquewqayebxaycewbxeu Table of Contents
|
Upload User Manual
Have you got an user manual for the EVGA Z390 FTW LGA 1151 ATX Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersEVGA Z390 FTW Specs | | | Chipset | Intel Z390 | | CPU Socket | LGA 1151 | | | | USB | 2 x USB 2.0 Type-A
4 x USB 3.1 Gen 2 Type-A | | Thunderbolt | None | | Display | None | | Audio | 5 x 3.5 mm
1 x S/PDIF | | Ethernet / Controller | 1 x Intel i219V Gigabit | | PS/2 | 1 x Combo | | | | Memory Slots | 4 x 288-Pin | | Memory Support | DDR4 4133 MHz | | Maximum Capacity | 64 GB | | Channel Architecture | Dual Channel | | | | SATA | 6 x SATA III | | M.2 | 1 x M Key 22110 (PCIe 3.0 x4, SATA III)
1 x M Key 2280 (PCIe 3.0 x4, SATA III) | | U.2 | None | | Optane Memory Support | Yes | | RAID Support | RAID 0, 1, 5, 10 (SATA)
RAID 0, 1 (M.2) | | | | Expansion Slots | 2 x PCIe x16
1 x PCIe x4
2 x PCIe x1 | | USB | 2 x USB 2.0 Header (Supports 4 USB Type-A Ports)
2 x USB 3.1 Gen 1 Header (Supports 4 USB Type-A Ports)
1 x USB 3.1 Gen 2 Header (Supports 1 USB Type-C Ports) | | Multi-GPU Support | 2-Way NVIDIA SLI | | Air Cooling | 2 x 4-Pin CPU
4 x 4-Pin System | | Power Connectors | 1 x 24-Pin Mainboard
1 x 8-Pin CPU | | Audio | None | | Diagnostics | Clear CMOS, Power, Reset | | | | I/O Connection Headers | USB 3.1 | | | | Audio Codec | Realtek ALC1220 (7.1-Channel) | | | | Module Support | 1 E Key M.2 | | | | Supported Operating Systems | Windows 10 (32/64-Bit)
Windows 8/8.1 (32/64-Bit)
Windows 7 (32/64-Bit) | | | | Form Factor | ATX | | Dimensions | 9.6 x 12" / 243.84 x 304.80 mm | | | | Package Weight | 3.2 lb | | Box Dimensions (LxWxH) | 13.0 x 11.0 x 4.0" |
