Product description Completely redesigned, the Explore Scientific 20" f/3.6 Truss Tube Gen 2 Dobsonian Telescope gets improvements to stiffness and load bearing capacity of the optical components to safely carry the large primary mirror and move the entire system smoothly with greater vibration suppression. All connections of the tube structure are welded, with no rivets or screws.The ability to produce the large 20" aperture gives users exceptional performance with a low dollar-to-aperture cost. Its oversized parabolic primary mirror is highly reflective and corrects spherical aberration to eliminate distortion across the entire field of view, especially at the edges. The large aperture draws in a tremendous amount of light to present awe-inspiring details of the Moon and planets, make deep sky objects visible even for inexperienced observers, and reveal bright star clusters with resolution down to their core. Its exceptional f/3.65 focal ratio and 10:1 dual-speed 2.5" helical focuser makes this an ideal choice for imaging. The fast focal ratio enables devices to capture images in less time than slower scopes with limited light loss to diffraction and diffusion, while the unique focusing mechanism employed in the helical design gives it the ability to achieve tack-sharp focusing with zero backlash, which rack-and-pinion focusers are generally unable to do. This focuser will accept larger 2" eyepieces so users can enjoy a truly immersive visual experience and will ensure larger imaging sensors are completely covered.The rocker box provides a rock-steady observational platform with very low vibration, and features high-altitude bearings with aluminum structures that allow for fine adjustment flows at high magnifications, and an array of fans in the box and at the primary mirror allows the telescope to quickly adjust to the ambient air temperature to reduce distortion. Finally, the tension control handle allows users to adjust the settings, allowing them to move the mount easily and smoothly by hand with minimal vibration and maintaining its position when released. - Optical Tube Assembly
-
- Open aluminum truss design maintains performance while reducing weight, without sacrificing strength or stiffness
- Oversized 20" / 500mm aperture draws in the light required for viewing deep space objects, like wispy nebulae and splitting binary stars, and reveals stunning lunar and planetary details
- Fast f/3.6 focal ratio ensures high light transmission through the optical system with limited diffraction or diffusion
- Long 1826mm focal length produces a high magnification potential
- Silvered aluminum mirror coatings boost reflectivity to greater than 94% to maximize image brightness
- 120mm secondary mirror, 24% obstruction
- Primary mirror and rocker box fans help to maintain mirror temperature to reduce distortion
- Fans run on eight user-supplied AA batteries
- Laser-engraved center mark on primary mirror enables easier collimation
- Includes collimation assist tool for adjustments in the field
- Mount
-
- Manual alt-azimuth rocker mount design
- Six supporting base feet improve stability to improve vibration suppression and smooth rotation
- High altitude bearings enable a wide adjustment and travel range, with smooth movement and limited vibration
- Tension control handle allows for smoother rotation to reduce vibrations and limit overcompensation
- Assembles and disassembles without tools
- Focuser
-
- Dual-speed focusing mechanism with 10:1 reducer enables fast coarse and precision fine focusing
- Large 2.5" helical design provides strength and stability for large and heavy eyepieces, and moves the drawtube forward and back without rotation to maintain optical performance through eyepiece or imaging system
- Accepts large 2" eyepieces to ensure a relatively large field of view at all magnification to keep objects within the eyepiece for the maximum amount of time before adjustments to the mount are required
- Helical focusers use a toothless design that allows for smooth and precise focusing without backlash
UPC: 811803030107 In the Box Explore Scientific 20" f/3.6 Truss Tube Gen 2 Dobsonian Telescope Collimation Assist Tool Red Dot LED Finderscope Limited 1-Year USA Warranty, Extendable to Transferrable Lifetime Warranty with Registration Table of Contents
|
Upload User Manual
Have you got an user manual for the Explore Scientific 20" f 3.6 Truss Tube Gen 2 Dobsonian Telescope in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersExplore Scientific DOB2036-00 Specs | | | Optical Design | Dobsonian Reflector | | Aperture | 508 mm / 20" | | Focal Length | 1826 mm | | Focal Ratio | f/3.6 | | Focuser | Dual-Speed Helical | | Eyepiece Barrel Diameter | 2" | | Diagonal | None | | Finderscope | Yes | | Optical Tube Dimensions | 70.5 x 27" / 179.1 x 68.6 cm | | | | Batteries | 8 x AA | | GPS | None | | Wi-Fi | None | | Weight | 116.0 lb / 52.6 kg |
