User Manual for Fantasea Line UWL-400Q Wide-Angle Wet Conversion Lens Click to enlarge the picture
Contents of the user manual for the Fantasea Line UWL-400Q Wide-Angle Wet Conversion
- Product category: Lenses Fantasea Line
- Brand: Fantasea Line
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Fantasea Line Lenses
 |
User manual for the Fantasea Line UWL-400Q Wide-Angle Wet Conversion contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Fantasea Line product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Fantasea Line user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Fantasea Line product will considerably shorten its lifespan!
|
Product description Attach the Fantasea Line UWL-400Q Wide-Angle Wet Conversion Lens to your underwater camera housing for clear, close, wide-angle images of the undersea world. Featuring a 120° field of view with zero minimum focus distance, this "wet" lens, which can be removed and replaced during the dive, is useful when photographing seascapes, divers, ship wrecks, and schools of fish, as well as over-and-under compositions. Its optical elements are anti-reflective multi-coated, and its optical glass dome bears a hard coating. Its wings can easily be rotated without tools to prevent glare on the dome from strobes or the sun. The lens is compatible with most 24mm (or higher focal range) camera lenses, and it can be used with some wider lenses by zooming in to avoid vignetting.
Constructed of aluminum alloy with a hard-black coating, the UWL-400Q has a 52mm mounting thread, and comes with an adapter that can be used to mount it on lens ports with 67mm threads. (It can also be used with separately sold Fantasea Line bayonet adapters.) A secure string with a snap hook allows the lens to be secured to the housing, even when removed from the lens port. - Optical Performance
-
- Wide 120° field of view (using 25mm lens) and no minimum focus distance
- Anti-reflective multi-coated lenses
- Magnification: 0.5x
- Five lens elements in five groups
- Hard-coated optical glass dome
- Permits close focus wide-angle and over-under compositions
- Construction Details
-
- Depth-rated 330'
- Hard-coated aluminum alloy lens housing and wings
- Wings are easily rotated to keep sun/strobe light off dome
- 52mm mounting thread
- Adapter for housings with 67mm threads
- Secure string
- Neoprene dome cover, lens cap & carry case
UPC: 665309051421 In the Box Fantasea Line UWL-400Q Wide-Angle Wet Conversion Lens Neoprene Dome Cover Rear Lens Cap EyeDaptor M67-F52 Lens Adapter Secure String Microfiber Cleaning Cloth O-Ring Remover Padded Carry Case Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Fantasea Line UWL-400Q Wide-Angle Wet Conversion Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersFantasea Line UWL-400Q Specs | Depth Rating | 330' / 100 m | | Magnification | 0.5x | | Field of View | 120° (with 25mm camera lens) | | Mounting Thread | 52 mm | | Dimensions | 4.8 x 3.0" / 121.8 x 76 mm | | Weight | 21.4 oz / 606 g on land
7.9 oz / 224 g in water | | | | Package Weight | 2.165 lb | | Box Dimensions (LxWxH) | 7.0 x 6.4 x 4.9" |
Rating80% users recommend this product to others. And what about you?
This product has already been rated by 67 owners. Add your rating and experience with the product.
