User Manual for FeelWorld 7" IPS Lightweight 3G-SDI HDMI Field Monitor with Peaking & Sunshade Click to enlarge the picture
Contents of the user manual for the FeelWorld 7" IPS Lightweight 3G-SDI HDMI
- Product category: On Camera Monitors FeelWorld
- Brand: FeelWorld
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for FeelWorld On Camera Monitors
 |
User manual for the FeelWorld 7" IPS Lightweight 3G-SDI HDMI contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any FeelWorld product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official FeelWorld user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a FeelWorld product will considerably shorten its lifespan!
|
Product description The 7" IPS Lightweight 3G-SDI HDMI Field Monitor with Peaking & Sunshade from FeelWorld features IPS technology, for both accurate color rendering and a wider viewing angle. It supports resolutions up to 1024 x 600 and offers a contrast ratio of 800:1. The ST702-HSD provides both 3G-SDI and HDMI signal loop-through ports, along with a 3.5mm mini headphone jack.The monitor supports peaking function for focusing assist, highlighting image edges in red. The pixel-to-pixel enables the filmmaker to check the image from the 1:1 signal source without scaling. In Blue mode, only the blue pixels are used to generate the image, allowing hue and saturation to be adjusted quickly and accurately. The setting knob and six shortcut keys make monitor settings adjustment a quick and easy process. - Wide viewing angle of 85° U/D, L/R
- Wide color gamut LCD panel ensures precise color representation
- Extended screen hood prevents light from affecting the display in almost all environments
- Supports camera mode and check field
- Supports center and screen markers
- Supports color temperature and image adjustment (4:3 and 16:9)
- Supports image flipping and freezing
In the Box FeelWorld 7" IPS Lightweight 3G-SDI HDMI Field Monitor with Peaking & Sunshade Mini HDMI Cable Sun Shade Hot Shoe Mount L-Series Type Battery Plate Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the FeelWorld 7" IPS Lightweight 3G-SDI HDMI Field Monitor with Peaking & Sunshade in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersFeelWorld ST-702HSD Specs | | | Resolution | 1024 x 600 pixels | | Dot Pitch | H x V: 0.05 x 0.15 mm | | Aspect Ratio | 16:9 | | Brightness | 600 cd/m² | | Contrast | 800:1 | | Viewing Angle | 85°/85°(L/R)
85°/85°(U/D) | | Backlight | LED | | | | SDI | 1080p 60/59.94/50/30/29.97/25/24/23.98
1080i 60/59.94/50
720p 60/59.94/50/30/29/25/24/23.98
576i
480i | | HDMI | 1080p 60/59.94/50/30/29.97/25/24/23.98
1080i 60/59.94/50
720p 60/59.94/50/30/29/25/24/23.98
576p / 576i
480p / 480i | | | | Input | 1 x SDI
1 x HDMI | | Output | 1 x SDI
1 x HDMI | | | | Audio | 1 x Speaker
1 x Earphone slot | | Input Voltage | 6 to 24 VDC | | Power Consumption | ≤ 9 W | | Working Temperature | -4 to 122°F (-20 to 50°C) | | Storage Temperature | -22 to 149°F (-30 to 65°C) | | Threads | 1/4"-20 thread socket on all four sides | | Dimensions | 7.6 x 5.8 x 1.1" (19.4 x 14.8 x 2.9 cm), without sunshade
7.6 x 5.9 x 2.4" (19.4 x 15.0 x 6.2 cm), with sunshade | | Weight | 18 oz (512 g), with battery plate
23.5 oz (669 g), with battery plate and sunshade | | | | Package Weight | 2.405 lb | | Box Dimensions (LxWxH) | 11.45 x 7.6 x 3.4" |
