Product description This second edition of the book Small Signal Audio Design from Focal Press will show you how to use inexpensive and readily available parts to obtain state-of-the-art performance in all the vital parameters of noise, distortion, crosstalk and more. With ample coverage of preamplifiers and mixers, and a new chapter on headphone amplifiers, this practical handbook provides an extensive repertoire of circuits that can be put together to make almost any type of audio system.
A resource packed full of valuable information, with virtually every page revealing nuggets of specialized knowledge not found elsewhere. Essential points of theory that bear on practical performance are lucidly and thoroughly explained, with the mathematics kept to a relative minimum. Douglas' background in design for manufacture ensures he keeps a wary eye on the cost of things. Includes a chapter on power-supplies, full of practical ways to keep both the ripple and the cost down, showing how to power everything.
You will learn why mercury cables are not a good idea, the pitfalls of plating gold on copper, and what quotes from Star Trek have to do with PCB design. The book will teach you how to: Make amplifiers with apparently impossibly low noise
-Design discrete circuitry that can handle enormous signals with vanishingly low distortion
-Use humble low-gain transistors to make an amplifier with an input impedance of more than 50 Megohms
-Transform the performance of low-cost-opamps, how to make filters with very low noise and distortion
-Make incredibly accurate volume controls
-Make a huge variety of audio equalizers
-Make magnetic cartridge preamplifiers that have noise so low it is limited by basic physics
-Sum, switch, clip, compress, and route audio signals
This second edition is expanded throughout, with added information on new ADCs and DACs, microcontrollers, more coverage of discrete op amp design, and many other topics. It includes a completely new chapter on headphone amplifiers. - Contents
- Introduction
1. Basics
2. Components
3. Designing with Discrete Transistors
4. Opamps and Their Properties
5. Filters
6. Preamplifier Architectures
7. Moving-Magnet Disc Inputs
8. Moving-Coil Disc Inputs
9. Volume-Control and Balance
10. Tone Controls and Equalizers
11. A Complete Preamplifier
12. Mixer Architectures
13. Microphone Input Amplifiers
14. Line Inputs
15. Line Outputs
16. Signal Switching
17. Mixer Subsystems
18. Level Indication and Metering
19. Level Control and Special Circuits
20. Power Supplies
21. Interfacing with the Digital Domain
22. Headphone Amplifiers Table of Contents
|
Upload User Manual
Have you got an user manual for the Focal Press Book: Small Signal Audio Design in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersFocal Press 978-0-415-70973-6 Specs | Author | Douglas Self | | Publisher | Focal Press | | Pages | 752 | | Format | Paperback | | ISBN Number | 9780415709736 | | Date Published | August, 2014 | | | | Package Weight | 3.0 lb | | Box Dimensions (LxWxH) | 9.2 x 7.4 x 1.5" |
